Fixing the Unit in Position
The outdoor unit must be installed on a rigid and stable base to
avoid any increase in the noise level and vibration, particularly if the
outdoor unit is to be installed close to a neighbour.
If it is to be installed in a location exposed to strong winds or at a
height, the unit must be fixed to an appropriate support (wall or
ground).
1 Position the outdoor unit so that the air flow is directed towards the out-
side, as indicated by the arrows on the top of the unit.
2 Attach the outdoor unit to the appropriate support using anchor bolts.
3 If the outdoor unit is exposed to strong winds, install shield plates around
the outdoor unit, so that the fan can operate correctly.
❇ Certainly fix up its rubber leg, in order to prevent its vibration and noise.
C
OMPLETING THE INSTALLATION
E-37
600 mm (23.62 inch)
Rubber leg
256 mm
(10.1inch)
AS12A1VC-E 1/26/00 3:16 PM Page 15
