Exploded Views and Parts List
5-14Samsung Electronics
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
1 DB64-01143A PANEL FRONT HIPS 1
2 DB66-00757B BLADE-H SAN/GF20 4
3 DB61-01871A CONNECTOR BLADE POM 8
4 DB61-01870A HOLDER BLADE ABS 8
5 DB66-00756A JOINT UNIVERSAL POM 6
6 DB66-00759A LINK MOTOR POM 2
7 DB66-00758A LINK BLADE POM 2
8 DB61-01872A BRACKET MOTOR SGCC-M 2
9 DB31-10129C MOTOR STEP GSP-24RW-045 2
10 DB64-01141A INLAY PCB PC 1
11 DB64-01142A BUTTON PCB ABS 1
12 DB93-02803A ASS'Y PCB DISPLAY ASS'Y 1
13 - WASHER - 1
14 DB69-00947A CUSHION IN EPS 4
15 DB69-00948A CUSHION OUT EPS 4
16 DB63-01014A COVER A HIPS 1
17 DB63-01015A COVER B HIPS 1
18 DB63-01016A COVER C HIPS 2
19 DB64-01144A GRILLE AIR INLET HIPS 1
20 DB74-00002A FILTER AIR COMPOSITION PP(UL94-HB) 1
21 DB64-01145A KNOB SLIDE HIPS 2
22 DB67-00030A SPRING KNOB STS304 2
23 DB63-01036A COVER KNOB HIPS 2
24 DB70-00302A PLATE HANGER STS304 2
25 DB65-00023A CLIP WIRE ASS'Y ASS'Y 1
26 DB39-00082D CONNECT WIRE M-D ASS'Y 1
27 DB39-00542C CONNECT WIRE MOTOR ASS'Y 1
28 6002-001079 SCREW TAPPING TH, +, 2S, M4, L10 17
29 6002-000536 SCREW TAPPING PH, +, 2S, M4, L8 8
30 6002-000534 SCREW TAPPING PH, +, 2S, M3, L8 1
31 DB72-00298A SEAL CUSHION FLOCKED 4
SNA
SA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SA
SNA
SA
SNA
SNA
SNA
SNA
SNA
SNA
SNA
SA
SNA
SNA
SNA
SNA
SNA
SA
SA
SNA
SNA
SNA
SNA
MGCH095IM1
