Disassembly and Reassembly
4-48Samsung Electronics
No Parts Procedure Remark
1 Electrical
Part
1) Open the Grille by pressing 3 position.
(center and both side)
2) Remove the air inlet Grille.
3) Open the cover of Electrical Component
Box by removing the screws.
(center and both side)
4-1-9 Ceiling type
24103A(1)_1 12/23/05 12:01 PM Page 3-57
To Next Page
