Disassembly and Reassembly
4-34Samsung Electronics
No Parts Procedure Remark
3 Heat Exchanger
Drain Board
1) Disassemble the screws on side part, then
Cabinet and the unit are separated.
2) It is possible to clean the surface of Heat
Exchanger and Drain Board.
3) After cleaning Heat Exchangers and Drain
Board, check whether the Drain exhaust
are clogged.
24103A(1)_1 12/23/05 12:01 PM Page 3-43
