Installing the Hob (Continued)
Installing into the countertop
Make a note of the serial number on the appliance rating plate prior to installation.
This number will be required in the case of requests for service and is no longer ac-
cessible after installation, as it is on the original rating plate on the underside of the
appliance.
Pay special attention to the minimum space and clearance requirements.
Secure the brackets at both sides with the provided screws before mounting the hob
onto the brackets.
Min. 50mm
560
min. 20
600
50
+1
R3
490
+1
x4
