32_ Operating advanced function
Operating advanced function
FIELD SETTING MODE
Field Setting Value (FSV) Table
•Code40:User’soptionsforheatingdevicesincludinginternalbackupheaterandexternalboiler
401:Space/DHWheatingpriorityandcontrolvariables
402:Backup/Boosterheaterpriorityandcontrolvariables
403:Additionalbackupboileroperatingvariables
•Code50:User’soptionsforextrafunctions
501:Newtargettemperaturesofeachmodeby“Outgoing”hotkeyofremotecontroller
 5021:Temperaturedifferencebetweenbefore&aftervaluesin“Economic”DHWmode
504:Preventionofthepeakpowerforusingthecontractelectricpower
FieldSettingValue
Main Menu &
Code
Sub Menu Function Description
Sub
Code
Default Min Max Step Unit
Heating Code
40
Heat Pump Heating/DHW Priority 11 0(DHW) 0 1(Heating) - -
Outdoor Temp for Priority 12 0 -15 20 1 ˚C
Heating Off 13 25 14 35 1 ˚C
Overshoot 14 2 1 4 1 ˚C
Backup Heater Application 21 1(On) 0(Off) 1 - -
BUH/BSH Priority 22 0(Both) 0 2(BSH) 1 -
For back-up use only 23 1(On) 0(Off) 1 - -
Threshold Temp 24 0 -15 35 1 ˚C
Backup Boiler Application 31 0(No) 0 1(Yes) - -
Boiler Priority 32 0(Off) 0 1(On) - -
Threshold Temp 33 -15 -20 5 1 ˚C
Others Code
50
Outing Water Out Temp for
Cooling
11 25 5 25 1 ˚C
Room Temp for Cooling 12 30 18 30 1 ˚C
Water Out Temp for
Heating
13 25 15 55 1 ˚C
Room Temp for Heating 14 16 16 30 1 ˚C
Auto Cooling WL1 Temp 15 25 5 25 1 ˚C
Auto Cooling WL2 Temp 16 25 5 25 1 ˚C
Auto Heating WL1 Temp 17 15 15 55 1 ˚C
Auto Heating WL2 Temp 18 15 15 55 1 ˚C
Target Tank Temp 19 30 30 70 1 ˚C
DHW Saving Mode Temp Difference 21 5 0 40 1 ˚C
Power Peak Control Application 41 0(No) 0 1(Yes) - -
Select forced off parts 42 1 0 3 - -
Using input voltage 43 1(High) 0(Low) 1 - -
