Samsung Control Unit - Page 31

Operating advanced function _31
ENGLISH
•Code30:User’soptionsfordomestichotwater(DHW)tankheating
 3011:ApplicationofDHWtankinuser’ssystem
302:Heatpumpvariablesfortanktemp.controlandcombinationwithboosterheater
303:Boosterheatervariablesforcombinationwithheatpump
304:Periodicaldisinfectionheatingofwatertank
305:OfftimerforpowerDHWmodebyhotkeyofwiredremotecontroller
 3061:CombinationofexternalfieldsolarpanelforwithheatpumpforDHWheating
307:DefaultdirectionoftheDHWvalveorZone#1,#2valve
FieldSettingValue
Main Menu &
Code
Sub Menu Function Description Sub Code Default Min Max Step Unit
DHW Code
30
Domestic Hot Water
Tank
Application 11 0(No) 0 1(Yes) - -
Heat Pump Max Temp 21 50 45 55 1 ˚C
Stop 22 2 2 10 1 ˚C
Start 23 5 1 20 1 ˚C
Min Operation 24 5 1 20 1 min
Max Operation 25 30 5 95 5 min
Interval 26 3 0.5 10 0.5 hour
Booster Heater Application 31 1(On)
0(OFF) 1 - -
Delay Time 32 20 20 95 5 min
Overshoot 33 0 0 4 1 ˚C
Compensation Temp 34 10 0 20 1 ˚C
Disinfection Application 41 1(On)
0(OFF) 1 - -
Interval 42 Fri Mon Sun 1(All) day
Start Time 43 23 0 23 1
o'clock
Target Temp 44 70 40 70 5 ˚C
Duration 45 10 5 60 5 min
Power DHW by User
Input
Timer OFF Function 51 0(Off) 0 1(On) - -
Timer Duration 52 60 30 300 10 min
Solar Panel H/P Combination 61 1(Yes) 0(No) 1(Yes) - -
3-way Valve Default direction 71 0(Room) 0 1(Tank) - -
Direction of the
valves
DHW valve or 3-way
valve
71 0(Tank) 0 1(Room) - -
Zone#1 72 1(Room) 0 1 - -
Zone#2 73 1(Room) 0 1 - -
