Appendix
TEMPERATURE TABLE
Available operation range
Mode Targettemperature
Display Settingrange
Current
display
Setting
method
Control
method
Set View Default Available
Cooling Leaving water O O 16~25˚C
•Min:5~18˚C
•Max:18~25˚C
-50~94˚C Up/Down -
Heating Leaving water O O 25~55˚C
•Min:15~37˚C
•Max:37~55˚C
-50~94˚C Up/Down -
Water
Law
Cooling
Outdoor X X 30~40˚C
•Min:25~35˚C
•Max:35~45˚C
-50~94˚C
Field
Setting
Mode
SET/VIEW
mode
Thermostat
(Th-1:Floor,
Th-2:FCU)
Leaving water
(WL1-Floor)
X X 25~18˚C
•Min:18~25˚C
•Max:5~18˚C
-50~94˚C
Leaving water
(WL2-FCU)
X X 18~5˚C
•Min:18~25˚C
•Max:5~18˚C
-50~94˚C
Heating
Outdoor X X -10~15˚C
•Min:-20~5˚C
•Max:10~20˚C
-50~94˚C
Leaving water
(WL1-Floor)
X X 40~25˚C
•Min:40~55˚C
•Max:17~37˚C
-50~94˚C
Leaving water
(WL2-FCU)
X X 50~35˚C
•Min:40~55˚C
•Max:17~37˚C
-50~94˚C
Temperature Shifting O X -5~5˚C Default - Up/Down -
DHW DHW tank O O 40~50˚C
•Min:30~40˚C
•Max:50~65˚C
-50~94˚C Up/Down -
Outdoor temperature X O - - -50~94˚C -
DIP SWITCH SETTING
S/W OFF(Default) ON
S/W #1 Heating and Cooling Heating only
S/W #2 Targettemp:WateroutletTemp. Targettemp:IndoorairTemp.
S/W #3 Air sensor in remote controller External air sensor
S/W #4 No Use No Use
S/W #5 No Use No Use
S/W #6 No Use No Use
S/W #7 No Use No Use
S/W #8 No Use No Use
