30_ Operating advanced function
Operating advanced function
FIELD SETTING MODE
Field Setting Value (FSV) Table
•Code10:Upperandlowertemperaturelimitsofeachoperationmodeofwiredremotecontroller
Heating(Water Out, Room), Cooling(Water Out, Room), DHW(Tank)
•Code20:Waterlawdesignandexternalroomthermostat
Heating(2 WL’s for floor & FCU), Cooling(2 WL’s for floor & FCU), WL & Thermostat
types
FieldSettingValue
Main Menu &
Code
Sub Menu Function Description
Sub
Code
Default Min Max Step Unit
Remote
Controller
Setting Range
Code 10
Water Out Temp for Cooling
Max 11 25 18 25 1 ˚C
Min 12 16 5 18 1 ˚C
Room Temp for Cooling
Max 21 30 24 30 1 ˚C
Min 22 18 18 22 1 ˚C
Water Out Temp for Heating
Max 31 55 37 55 1 ˚C
Min 32 25 15 37 1 ˚C
Room Temp for heating
Max 41 30 24 30 1 ˚C
Min 42 16 16 22 1 ˚C
DHW Tank Temp
Max 51 50 50 70 1 ˚C
Min 52 40 30 40 1 ˚C
Water Law
Code 20
Outdoor Temp for Water Law
(Heating)
Point

11 -10 -20 5 1 ˚C
Point

12 15 10 20 1 ˚C
Water Out Temp for WL1 Heating
(WL1-Floor)
Point

21 40 40 55 1 ˚C
Point

22 25 17 37 1 ˚C
Water Out Temp for WL2 Heating
(WL2-Fan Coil Unit)
Point

31 50 40 55 1 ˚C
Point

32 35 17 37 1 ˚C
Heating Water Law for Auto Mode WL Type 41 1(WL1) 1
2(WL2) - -
Outdoor Temp for Water Law
(Cooling)
Point

51 30 25 35 1 ˚C
Point

52 40 35 45 1 ˚C
Water Out Temp for WL1 Cooling
(WL1-Floor)
Point

61 25 18 25 1 ˚C
Point

62 18 5 18 1 ˚C
Water Out Temp for WL2 Cooling
(WL2-Fan Coil Unit)
Point

71 18 18 25 1 ˚C
Point

72 5 5 18 1 ˚C
Cooling Water Law for Auto Mode WL Type 81 1(WL1) 1
2(WL2) - -
External Thermostat Application
#1(Floor) 91 0(No) 0 1(Yes) - -
#2(FCU) 92 0(No) 0 1(Yes) - -
