Samsung CS29A6WT8X/BWT - Page 38

C115 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C116 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C244 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C245 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C248 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C250 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C113 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V
C623 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C624 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C627 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C629 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C638 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C639 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C642 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C644 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C701 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C702 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C923 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
C647 2202-000286 C-CERAMIC,MLC-AXIAL;56pF,5%,50V,SL,TP,1.
C211 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C607 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C608 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C905 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C632 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
C908 2202-000863 C-CERAMIC,MLC-AXIAL;560pF,10%,50V,Y5P,TP
C218 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C219 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C220 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C221 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C222 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C223 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C232 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C901 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C919 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C921 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C922 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C411 2301-000104 C-FILM,PEF;1.2nF,5%,50V,TP,6.5x3.0x5.5mm
C649 2301-000108 C-FILM,PEF;1.5nF,5%,50V,TP,6.5x3.0x5.5mm
C821 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C902 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C410 2301-000213 C-FILM,PEF;220nF,5%,250V,TP,21.5x11,7.5
C212 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C416 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C213 2301-000247 C-FILM,PEF;33nF,5%,50V,TP,8.1x4.5x13mm,5
C811 2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X5,
C412 2301-000313 C-FILM,PEF;8.2nF,5%,100V,TP,7x3.2x7mm,5m
C306 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,
C228 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C230 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C809 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C810 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C103 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C105 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C909 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C415 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
C610 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
C611 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
C420 2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7.
C425 2301-001259 C-FILM,MPPF;100nF,5%,400V,TP,19x8x16,7.5
C409 2301-001268 C-FILM,PPF;33nF,5%,630V,TP,20x11x17,7.5
C429 2303-000163 C-FILM,PPF;2.2nF,5%,800V,TP,15x13x8.5,7.
C807 2303-000163 C-FILM,PPF;2.2nF,5%,800V,TP,15x13x8.5,7.
C305 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
C304 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15
C408 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm
C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C235 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C236 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C308 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C907 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C214 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C216 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C605 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C620 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C635 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C646 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C825 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C831 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C837 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C839 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C914 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C916 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C637 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C640 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C641 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C643 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C912 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C104 2401-000133 C-AL;1000uF,20%,16V,GP,TP,10x20,5
C826 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5
C816 2401-000293 C-AL;100uF,+30-10%,200V,GP,TP,16x25
C302 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C307 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C413 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C617 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C917 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C201 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C301 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C604 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C106 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5
C841 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5
C818 2401-000722 C-AL;2200uF,20%,25V,WT,TP,16x25,7.5
C237 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C208 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
C217 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
C636 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
C402 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
C404 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
C422 2401-001527 C-AL;47uF,20%,250V,HR,TP,13x25mm,5m
C634 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C832 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C838 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C913 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C915 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C918 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C612 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
C613 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
C622 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C625 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C626 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C628 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C707 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C827 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5
C840 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5
C202 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C205 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C215 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C231 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C603 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C630 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C631 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C645 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C652 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C708 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C920 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C427 2401-002267 C-AL;2.2uF,20%,250V,GP,TP,8x11.5,5
C835 2401-002289 C-AL;470uF,20%,35V,WT,TP,10x20,5
C621 2401-002458 C-AL;1000uF,20%,35V,GP,TP,16x25,7.5
C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
C418 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
C229 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
C833 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
C823 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
C824 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
C808 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
CW901 2503-000156 C-NETWORK;100pFx4,20%,50V
J706 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
J718 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L201 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L301 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L406 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
Electrical Parts List
Samsung Electronics 7-5
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
