L711 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L907 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L103 2701-000115 INDUCTOR-AXIAL;10uH,10%,3x7mm
L208 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L209 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L210 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L212 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L709 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L710 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L604 2701-000169 INDUCTOR-AXIAL;3.9uH,10%,2.5x3.4mm
L605 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L606 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L607 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L608 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L701 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L702 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L705 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L706 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
L902 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
L908 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
L909 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
L102 2701-000200 INDUCTOR-AXIAL;5.6uH,10%,4.2x9.8mm
L901 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
L903 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
L904 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13PF,
X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28-AAM,20pF,40oh
X601 2801-003903 CRYSTAL-UNIT;18.432MHz,25ppm,28-AAM,12pF
L407 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L601 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L609 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
J901 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L207 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L302 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L303 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L410 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L412 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L802 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L803 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L804 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L809 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L801 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
L806 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
FA802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS
FA803S 3601-001228 FUSE-AXIAL LEAD;125V,10A,FAST-ACTING,EPO
F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
CN602 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH
CN901 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH
CN302 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5MM,STRAIGH
CN502 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
CN704 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
CN702 3711-002647 CONNECTOR-HEADER;BOX,8P,1R,2.5mm,STRAIGH
HIC201 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
HIC202 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
HIC203 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
HIC204 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
PCB AA41-00168CPCB-MAIN;KS3A,FR-1,1L,C,1.6T,330x245,-,
R212 2004-000218 R-METAL;10Kohm,1%,1/8W,AA,TP,1.8x3.2mm
C803 2401-003576 C-AL;470uF,20%,450V,GP,ST,35x45mm,1
ASSY CHASSIS PART
* AA90-30213DASSY CHASSIS PART;KS3A,295A
D-FOCU 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
TB+HC 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
AA61-20254AHOLDER-CHASSIS;-,CS-622A,HIPS,V0,BLK,-
AV AA65-00011CCLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M
ASSY CABINET FRONT
* AA91-00113HASSY CABINET FRONT;-,CS-29A5WT KS3A PLAN
* AA90-70133WASSY CABINET;29A5,CS29A5WT8X/XSG
BRK+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR
CP+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR
TER+RJ 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR
CF+AV 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZPC(BLK),SWR
DOME AA60-10050ASCREW-ASSY;WP,RH,+,M4,L25,SWRCH18A,-,ZPC
CB+TER AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW
CF+CB AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW
CTS+CB AA60-10050T SCREW-TAPPING;RH,+,2S,M4,L20,ZPC(BLK),SW
CRT+CF AA60-10050VSCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S
AA61-10054ABRACKET-CRATER;-,6277,STS304,T0.5,-,-,-
AA63-30213DCOVER-TOP,SPK;-,29A5,-,HIPS,HB,BLK,-,-
CABBAC AA63-60001XSPACER-FELT;FELT,T0.5,BLK,330X15,-,-
CRT AA63-60004GSPACER-GUM,CRT;NTR RUBBER,T3.0,GRY,-,-,-
AA64-01230BINLAY-COVER;D2,D3,PVC-SHEET,T0.4,94V0,-,
AA64-31107DCABINET-BACK;-,29A5,-,HIPS,HB,BLK,-,-
AA65-30008ACLAMP-CORD;PE,HB,BLK,-,-,-
AA65-30017ACLAMP-D,COIL;NYLON-66,V0,NTR,DADH300,25
D-COIL AA65-30113ACLAMP-D,COIL;NYLON 66,V2,BLK,TVI 25~29,-
KNOPOW AA61-60005DSPRING-CS;-,SUS304,0.4,OD5.5,H9,N4,-,-,-
AA64-10709AKNOB-MASTER;-,295A,VT803M MASTER,ABS,HB,
AA64-10710AKNOB-CONTROL;-,725A,-,ABS,HB,GRAY
AA64-31106JCABINET FRONT;CS-29A5WT KS3A PLANO,S704P
AA64-40455AWINDOW-REMOCON;-,725A,-,PC,-,VIOLET,-
AA64-40456BINDICATOR-LED;-,295A,-,ACRYL,-,CLR,-
AA64-60445VINLAY AV;29A5,PS SHEET,-,-,BLK,-,KS3A E
AA64-60446CINLAY—PC,JACK;29A6,L/GRAY,PS SHEET,T0.5
AA64-70117BBADGE-BRAND;AL,SS,SILVER,L65,R2000,-,-
AA65-00011CCLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M
ASSY HOLDER SPK
* AA91-00333BASSY HOLDER SPK;-,PP,8ohm/15W,BLK,AA91-0
ASSY TERMINAL BOARD
* AA91-00368BASSY TERMINAL BOARD;-,HIPS,V0,BLK,KS3A R
AA63-40254BTERMINAL-BOARD,ANT;-,HIPS HB,BLK KCT55A,
AA64-01036CINLAY BACK;29A5,PS SHEET,T0.5,-,BLK,-,PC
ASSY ACCESSORY
* AA94-02704AASSY ACCESSORY;CS29A5WT8X/XSG,KS2A,U.A.E
AA39-40001BCABLE-RCA;-,RCA,1500mm,0.12/10,RED/WHT/Y
AA68-01013AMANUAL USERS;-,-,ARB.,-,W/P100G,ALL1,-,B
AA68-01016AMANUAL USERS;-,-,ENG,-,W/P100G,ALL1,-,B5
ASSY-CRT
* AA94-50022DASSY-CRT;A68QCP891X001,+380MG,29,ITC,C
AA03-00075ACRT-COLOR;-,A68QCP891X003(C),+380MG,29IN
ASSY PCB CONTROL
* AA95-00681AASSY PCB CONTROL;-,KS3A,29A5,PAL
LDY01 0601-000198 LED;ROUND,RED/GRN,5.0mm,630/565nm
CY01 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
SW811S 3403-000179 SWITCH-PUSH;250V,5A,DPST,-,JPW-2104B
SWY02 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
SWY03 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
Electrical Parts List
7-6 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
