SWY04 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
SWY05 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
SWY06 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
SCREW 6001-000057 SCREW-MACHINE;RH,+,M3,L6,ZPC(BLK),SWRCH1
PCB AA41-00299APCB-CONTROL;CS29A5WT,FR-1,1L,A,1.6T,245x
RMY01 AA59-60002BMODULE-REMOCON;-,ORC-50HF,38KHZ,940MM,ME
DZY01 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
RY03 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RY05 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RY01 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M
RY02 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RY04 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
CN811 AA39-20179F LEAD CONNECTOR-ASSY;-,-,-,3(2)P,-,-,-,YF
CNY01 AA39-20546ELEAD CONNECTOR-ASSY;-,-,-,5P,-,-,-,YBNH2
CNY02 AA39-00106BLEAD CONNECTOR-ASSY;-,-,-,4P,-,-,-,YBNH2
ASSY-PCB,A/V SIDE
* AA95-00682AASSY-PCB,A/V SIDE;-,29A6,29A5,KS3A,PAL,-
JH701 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO
JA701 3722-001031 JACK-RCA;3P,3.6MM,#18,AU
JS701 3722-001163 JACK-VHS;4P,12mm,AU,BLK,N
CN704 AA39-00070ALEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB
CN705 AA39-20009ELEAD CONNECTOR-ASSY;-,YFH800-01,-,1P,600
CN701 AA39-20068GLEAD CONNECTOR-ASSY;-,YBNH025-08,67096-0
CN703 AA39-20069ALEAD CONNECTOR-ASSY;-,YBNH025-05,67096-0
PCB AA41-00155APCB-SIDE AV;KS3A,1L,FR-1,245x245x1.6T,8A
R701 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
R702 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
C701 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C702 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C704 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C707 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C708 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C705 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C706 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
L701 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L703 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L704 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L707 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L708 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L705 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L706 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
CN702 AA39-20070JLEAD CONNECTOR-ASSY;-,-,-,7P,-,-,-,YBNH2
ASSY-POWER,CORD
* AA96-20109CASSY-POWER,CORD;-,CP2/NO(4.0),H/C300,KKP
AA39-10006XPOWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P,
AA61-20284AHOLDER;-,P-CORD,PP,VO,BLK,KE-002
REMOCON
* AA59-00104AREMOCON;-,TM59,DREAM,29,L/GRAY,-,EX,PA
Electrical Parts List
Samsung Electronics 7-7
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
To Next Page
