ASSY PCB MAIN(OPT)
* AA94-02037DASSY PCB MAIN(OPT);CS29A6WT8X/BWT,KS3A,R
IC903 1203-001944 IC-POSI.FIXED REG.;78RM33,TO-220,3P,-,PL
C820 2401-003076 C-AL;3300uF,20%,50V,WP,BK,18x35.5mm
JA701 3722-000195 JACK-SCART;42P,-,SN,BLK,NO
IC901 AA09-00041AIC-MCU;SDA555X-OTP,SDA555X-OTP,-,-,52
T801S AA26-00046ATRANS SWITCHING;-,-,-,AC90~260V,DC135/16
C-BLOC AA26-00069ATRANS FBT;FUJ-29C002C(S),DREAM3,4,-,-,-,
T444S AA26-00071ATRANS FBT;FUJ-29C007(S),W32,2.9mH,-,-,-,
L403 AA27-00014ACOIL-LINEARLITY;-,27UH,YL-81 DR15X18,-,-
L408 AA27-00056ACOIL HORIZ. WIDTH;-,600uH,YL9N 15x27.5 C
L405 AA27-00057ACOIL HORIZ. WIDTH;-,10mH,YL-9N 15x27.5 C
L402 AA27-00067ACOIL HORIZ. WIDTH;-,240uH,YL9N 12x20 C:6
L808 AA27-10002L COIL-CHOKE;-,24UH,K,-,2A,-,24UH-K,10X10M
D-COIL AA27-20002QCOIL-DEGAUSSING;-,29,14ohm,70T,L3300,E
TUBE AA39-00108ALEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,GR
AA39-20010CLEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,600
AA95-00561AASSY-DYNAMIC FOCUS;-,29A6,KS3A,PAL,-,-
CH07 2306-000327 C-FILM,MPPF;6.3nF,3%,1.6KV,TP,28.5x18x10
CH10 2303-000128 C-FILM,PPF;12nF,5%,1.6KV,BK,31x21x14,25m
ICH01 1201-000191 IC-OP AMP;4558,DIP,8P,300MIL,DUAL,20V/mV
LH01 AA26-00011ATRANS-DUMMY;-,3.5MH,EE2834,-,BK
LH02 AA27-40003J COIL-HORIZ.WIDTH;-,3mH,ER14 20,PI0.35,ST
QH01 0502-000442 TR-POWER;2SC4636RB,NPN,2W,TO-220,ST,10-
WIRE1 AA39-20010ALEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,200
WIRE3 AA39-20061CLEAD CONNECTOR-ASSY;-,YFH800-03,S,3P,200
AA99-20069WASSY-PCB SUB,AUTO; AA95-00561A ,V
CH01 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CH02 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
CH03 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CH04 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
CH05 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CH06 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5
CNH01 AA39-20566CLEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB
PCB AA41-00152CPCB-DOUBLE FOCUS;CW29A6VN8X/XEF,FR-1,1L,
QH02 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
QH03 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QH04 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
RH01 2001-001165 R-CARBON(S);56OHM,5%,1/2W,AA,TP,2.4X6.4M
RH02 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH03 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH04 2001-001144 R-CARBON(S);4.7KOHM,5%,1/2W,AA,TP,2.4X6.
RH05 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA,TP,2.4X6.4
RH06 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
RH07 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RH08 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
RH09 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH10 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH11 2001-001107 R-CARBON(S);220ohm,5%,1/2W,AA,TP,2.4x6.4
RH12 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH13 2001-001139 R-CARBON(S);39KOHM,5%,1/2W,AA,TP,2.4X6.4
RH14 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH15 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RH16 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4
RH17 2001-001144 R-CARBON(S);4.7KOHM,5%,1/2W,AA,TP,2.4X6.
RH18 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
RH19 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4
RH20 2003-002193 R-METAL OXIDE(S);33Kohm,5%,2W,AG,TP,3.9X
RH21 2003-002193 R-METAL OXIDE(S);33Kohm,5%,2W,AG,TP,3.9X
RH22 2003-002193 R-METAL OXIDE(S);33Kohm,5%,2W,AG,TP,3.9X
RH23 2001-001055 R-CARBON(S);1.8KOHM,5%,1/2W,AA,TP,2.4X6.
RH28 2008-001113 R-FUSIBLE(S);0.22ohm,10%,2W,AG,TP,3.9x12
AA95-00683AASSY-PCB,VIDEO S/W;-,29A6,KS3A,PAL,-,-
CNS01 3711-002704 CONNECTOR-HEADER;NOWALL,6P,1R,2.5mm,ANGL
CNS02 3711-002706 CONNECTOR-HEADER;NOWALL,8P,1R,2.5mm,ANGL
ICS01 1001-001114 IC-VIDEO SWITCH;TEA6425,VIDEO SWITCH ,DI
AA99-20075BASSY-PCB SUB,AUTO; AA95-00683A ,V
CS01 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS02 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS03 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS04 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS05 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS06 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
CS07 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
CS08 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
LS01 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
PCB AA41-00153DPCB-VIDEO SWITCH;CS29A6,FR-1,1L,D,1.6T,2
QS01 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QS02 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QS03 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
RS01 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
RS02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RS03 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS04 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RS05 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS06 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RS07 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS10 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RS11 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AA95-00700AASSY PCB CRT;-,KS3A,29A6,-,PAL
1P1 AA39-20010DLEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,400
1P2 AA39-20010DLEAD CONNECTOR-ASSY;-,YFH800-01,S,1P,400
CN501A 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
CN501E AA39-20025F LEAD CONNECTOR-ASSY;-,67096-010,S,10P,50
CN502E AA39-20029KLEAD CONNECTOR-ASSY;-,67096-007,S,7P,400
IC501 1201-001131 IC-VIDEO AMP;6111,SIP,9P,-,SINGLE,-,PLAS H/SINK
IC502 1201-001131 IC-VIDEO AMP;6111,SIP,9P,-,SINGLE,-,PLAS H/SINK
IC503 1201-001131 IC-VIDEO AMP;6111,SIP,9P,-,SINGLE,-,PLAS H/SINK
ICG01 1201-000191 IC-OP AMP;4558,DIP,8P,300MIL,DUAL,20V/mV
QF04 0502-000153 TR-POWER;2SC2344-D,NPN,1.2W,TO-220,-,60 H/SINK
QF05 0502-000131 TR-POWER;2SA1011-D,PNP,1.2W,TO-220,-,60 H/SINK
R523 2008-000255 R-FUSIBLE(S);1.5ohm,5%,1W,AA,TP,3.9x10mm
VA999 3704-001032 SOCKET-CRT;8P,29PI,35.5PI,AU30U
AA99-20075CASSY-PCB SUB,AUTO; AA95-00700A ,V
C103 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C104 2401-000133 C-AL;1000uF,20%,16V,GP,TP,10x20,5
C105 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C106 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5
C113 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V
C115 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C116 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C201 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C202 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C205 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C208 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
C211 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C212 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C213 2301-000247 C-FILM,PEF;33nF,5%,50V,TP,8.1x4.5x13mm,5
C214 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C215 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C216 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C217 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
C218 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C219 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C220 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C221 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C222 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C223 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C224 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
C225 2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
C228 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C229 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
C230 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C231 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C232 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
Electrical Parts List
7-8 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
7-2 CS29A6WT8X/BWT
