Samsung CS29A6WT8X/BWT - Page 42

C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C235 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C236 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C237 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C244 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C245 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C248 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C250 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C301 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C302 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C303 2201-002103 C-CERAMIC,DISC;0.015nF,5%,500V,NP0,TP,6.
C304 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15
C305 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
C306 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,
C307 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C308 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C401 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
C402 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
C403 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
C404 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
C405 2306-000330 C-FILM,MPPF;7.7nF,3%,1.6KV,TP,28.5x18.5x
C406 2306-000330 C-FILM,MPPF;7.7nF,3%,1.6KV,TP,28.5x18.5x
C407 2301-001338 C-FILM,MPE-PPF;0.68nF,5%,1.6kV,TP,28x7x1
C408 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm
C409 2301-001268 C-FILM,PPF;33nF,5%,630V,TP,20x11x17,7.5
C410 2301-000213 C-FILM,PEF;220nF,5%,250V,TP,21.5x11,7.5
C411 2301-000104 C-FILM,PEF;1.2nF,5%,50V,TP,6.5x3.0x5.5mm
C412 2301-000313 C-FILM,PEF;8.2nF,5%,100V,TP,7x3.2x7mm,5m
C413 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
C415 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
C416 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C418 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
C419 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C420 2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7.
C421 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
C422 2401-001527 C-AL;47uF,20%,250V,HR,TP,13x25mm,5m
C423 2301-001192 C-FILM,MPPF;820nF,5%,400V,TP,29x18.5x25.
C424 2201-000132 C-CERAMIC,DISC;0.1nF,10%,500V,Y5P,TP,6.5
C425 2301-001259 C-FILM,MPPF;100nF,5%,400V,TP,19x8x16,7.5
C426 2306-000204 C-FILM,MPPF;430nF,5%,400V,TP,26x20.5x12.
C427 2401-002267 C-AL;2.2uF,20%,250V,GP,TP,8x11.5,5
C429 2303-000163 C-FILM,PPF;2.2nF,5%,800V,TP,15x13x8.5,7.
C501 2201-000247 C-CERAMIC,DISC;0.015nF,5%,50V,NP0,TP,5x3
C502 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C503 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C505 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C506 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C507 2201-000247 C-CERAMIC,DISC;0.015nF,5%,50V,NP0,TP,5x3
C508 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C509 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C510 2401-001563 C-AL;47uF,20%,400V,GP,TP,16x25,7.5
C511 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5
C512 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C513 2201-002063 C-CERAMIC,DISC;10nF,+80-20%,3KV,Y5V,TP,1
C514 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
C515 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C516 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C518 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C519 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C520 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C521 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C522 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C523 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C526 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C601 2201-000558 C-CERAMIC,DISC;0.47nF,10%,50V,Y5P,TP,5x3
C603 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C604 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C605 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C607 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C608 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C610 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
C611 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
C612 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
C613 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
C617 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C620 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C621 2401-002458 C-AL;1000uF,20%,35V,GP,TP,16x25,7.5
C622 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C623 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C624 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C625 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C626 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C627 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C628 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C629 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C630 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C631 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C632 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP
C634 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C635 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C636 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
C637 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C638 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C639 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C640 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C641 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C642 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C643 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C644 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C645 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C646 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C647 2202-000286 C-CERAMIC,MLC-AXIAL;56pF,5%,50V,SL,TP,1.
C649 2301-000108 C-FILM,PEF;1.5nF,5%,50V,TP,6.5x3.0x5.5mm
C652 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C654 2201-000611 C-CERAMIC,DISC;0.056nF,5%,50V,NP0,TP,7x3
C656 2201-000304 C-CERAMIC,DISC;0.001nF,0.25pF,50V,NP0,TP
C657 2201-000304 C-CERAMIC,DISC;0.001nF,0.25pF,50V,NP0,TP
C701 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C702 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C707 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
C708 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C803 2401-003576 C-AL;470uF,20%,450V,GP,ST,35x45mm,1
C804 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250V,Y5U,TP,9x4
C805 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250V,Y5U,TP,9x4
C807 2303-000163 C-FILM,PPF;2.2nF,5%,800V,TP,15x13x8.5,7.
C808 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
C809 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C810 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C811 2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X5,
C814 2201-000406 C-CERAMIC,DISC;0.27nF,10%,2kV,Y5P,TP,6.3
C815 2401-003026 C-AL;330uF,20%,200V,GP,ST,22x35,10
C816 2401-000293 C-AL;100uF,+30-10%,200V,GP,TP,16x25
C817 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C818 2401-000722 C-AL;2200uF,20%,25V,WT,TP,16x25,7.5
C819 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C821 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C822 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C823 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
C824 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
C825 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C826 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5
C827 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5
C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C831 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C832 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C833 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
C835 2401-002289 C-AL;470uF,20%,35V,WT,TP,10x20,5
C837 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C838 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C839 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C840 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5
C841 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5
C901 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C902 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C905 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C907 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C908 2202-000863 C-CERAMIC,MLC-AXIAL;560pF,10%,50V,Y5P,TP
C909 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C910 2201-000980 C-CERAMIC,DISC;0.03nF,5%,50V,NP0,TP,5x3,
C911 2201-000980 C-CERAMIC,DISC;0.03nF,5%,50V,NP0,TP,5x3,
C912 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5
C913 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
Electrical Parts List
Samsung Electronics 7-9
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
