C914 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C915 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C916 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C917 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C918 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
C919 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C920 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C921 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C922 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C923 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP
CF01 2201-000179 C-CERAMIC,DISC;10nF,10%,50V,Y5V,TP,6.5x3
CF02 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
CF03 2201-000376 C-CERAMIC,DISC;0.22nF,5%,50V,SL,TP,6.3x3
CF04 2201-000653 C-CERAMIC,DISC;0.068nF,5%,50V,SL,TP,5x3,
CF05 2301-000261 C-FILM,PEF;4.7nF,5%,100V,TP,10.5x12.5x6.
CF06 2201-000516 C-CERAMIC,DISC;4.7nF,+100-0%,500V,Y5U,TP
CF07 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
CF08 2201-000604 C-CERAMIC,DISC;0.056nF,+100-0%,500V,SL,T
CF10 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CF11 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5
CF12 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
CF14 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CG01 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CG02 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
CG03 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
CG04 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
CN302 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5MM,STRAIGH
CN501 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
CN502 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
CN502A 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
CN602 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH
CN702 3711-002647 CONNECTOR-HEADER;BOX,8P,1R,2.5mm,STRAIGH
CN704 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
CN901 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH
CN902 3711-003043 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH
CNF01 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5MM,STRAIGH
CNG01 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5MM,STRAIGH
CW901 2503-000156 C-NETWORK;100pFx4,20%,50V
CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
CX802S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm
CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x
D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D202 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D203 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D204 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D205 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D206 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D207 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D208 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D209 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D210 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D211 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D301 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D401 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
D402 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T
D403 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D404 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
D405 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L
D406 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D407 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D408 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L
D409 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP
D411 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D412 0402-000010 DIODE-RECTIFIER;RGP15G,400V,1.5A,DO-204A
D413 0402-000537 DIODE-RECTIFIER;RH1A,600V,0.6A,DO-204AC
D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D507 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D508 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D509 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D510 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D511 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D512 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D601 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D602 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D801 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20
D801S 0402-000549 DIODE-BRIDGE;RBV606,600V,6A,-,BK H/SINK
D803 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D804 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D808 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D810 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D811 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D816 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
D901 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D902 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D905 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP
D906 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
D907 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D909 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DF01 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DF02 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
DF03 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
DF04 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DG01 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ202 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ203 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO
DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
DZ303 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
DZ304 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,D
DZ305 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D
DZ306 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
DZ401 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
DZ402 0401-000005 DIODE-SWITCHING;1N4148,100V,200MA,DO-35,
DZ503 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
DZ504 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
DZ505 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
DZ601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
DZ603 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ801 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO
DZ802 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ803 0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500
DZ804 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
DZ805 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL
DZ806 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ808 0403-000719 DIODE-ZENER;MTZJ7.5B,7.5V,7.07-7.45V,500
DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ906 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZ907 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
DZF01 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
DZF02 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
FA802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS
FA803S 3601-001228 FUSE-AXIAL LEAD;125V,10A,FAST-ACTING,EPO
FP801S 3601-000297 FUSE-CARTRIDGE;250V,5A,TIME-LAG,GLASS,5.
HC401 0402-001296 DIODE-RECTIFIER;FMP-3FU,1.5KV,5A,TO-3PF, H/SINK
HC401 0502-001136 TR-POWER;KSD5703,NPN,70W,TO-3PF,ST,8- H/SINK
HC801 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,- H/SINK
HC801 0402-001230 DIODE-RECTIFIER;FMG-G2CS,1000V,3A,TO-220 H/SINK
HC801 1203-001006 IC-VOLTAGE REGULATOR;78R05,TO-220F,4P,-, H/SINK
HIC201 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
HIC202 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
HIC203 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
HIC204 AA13-00093AIC HYBRID;-,DRGB001A,SIP,5P,-,TP
IC201S 1204-001633 IC-VIDEO PROCESS;VDP3112B-C3,DIP,64P,709
IC301 1204-000517 IC-VERTIVAL DEF.;LA7845,SIP,7P,-,PLASTIC H/SINK
IC401 1202-000103 IC-VOLTAGE COMP.;393,DIP,8P,300MIL,DUAL,
IC601 1204-001596 IC-SOUND PROCESSOR;MSP3400D-B4,SDIP,52P,
IC602 1201-001064 IC-POWER AMP;7297,ZIP,15P,-,DUAL,32DB,PL H/SINK
IC801S 1203-001482 IC-PWM CONTROLLER;3S1265R,TO-3P,5P,210,P H/SINK
IC803 1203-001697 IC-VOLTAGE REGULATOR;78R08,TO-220,4P,-,P
IC804 1203-000284 IC-POSI.FIXED REG.;7806,TO-220,3P,-,PLAS H/SINK
IC902 1103-001171 IC-EEPROM;24L161,16KBIT,DIP,8P,300MIL,10
IC904 1203-001943 IC-VOL. DETECTOR;7025,TO-92,3P,-,PLASTIC
J706 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
J718 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
J901 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
J904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
7-10 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
To Next Page
