JA501 3722-001503 JACK-PIN;1P,1PI,NI,RED,SCR-JACK
L102 2701-000200 INDUCTOR-AXIAL;5.6uH,10%,4.2x9.8mm
L103 2701-000115 INDUCTOR-AXIAL;10uH,10%,3x7mm
L201 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
L207 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L208 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L209 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L210 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L212 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L301 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L302 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L303 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L401 2001-001038 R-CARBON(S);0.56OHM,5%,1/2W,AA,TP,2.4X6.
L406 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L407 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L410 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L412 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L501 2701-000178 INDUCTOR-AXIAL;33uH,10%,3x7mm
L503 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L504 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L505 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L601 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L604 2701-000169 INDUCTOR-AXIAL;3.9uH,10%,2.5x3.4mm
L605 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L606 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L607 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L608 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L609 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L701 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L702 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L705 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L706 2701-000177 INDUCTOR-AXIAL;33uH,10%,2.5x3.4mm
L709 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L710 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L711 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L801 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
L802 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L803 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L804 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L806 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,-
L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L809 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L901 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
L902 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
L903 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
L904 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm
L905 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
L907 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L908 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
L909 2701-000191 INDUCTOR-AXIAL;47uH,10%,2.5x3.4mm
LF01 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
LF02 2701-000112 INDUCTOR-AXIAL;100uH,10%,3x7mm
LF04 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
LF05 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
LX801S AA29-00011AFILTER LINE NOISE;CZ32W8,-,0.20MAX,1.5KV
LX802S AA29-00011AFILTER LINE NOISE;CZ32W8,-,0.20MAX,1.5KV
NT802S 1404-001045 THERMISTOR-NTC;4.7OHM,15%,2900K,35.0MW,T
PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
PCB AA41-00210CPCB-CRT;CS29A6,FR-1,1L,C,1.6T,330x245,
PCB AA41-00168CPCB-MAIN;KS3A,FR-1,1L,C,1.6T,330x245,-,
PT801S 1404-000002 THERMISTOR-PTC;9ohm,20%,-,-,TR,RECT,-
Q201 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q203 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6
Q404 0505-000156 FET-SILICON;IRF620,N,200V,5A,0.8ohm,50W,
Q502 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
Q503 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
Q504 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
Q601 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q701 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q802 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,
Q901 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q902 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q903 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q904 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q905 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q906 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q908 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
Q909 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
Q910 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m
QF01 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QF02 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
QF03 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,
QG01 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
QG02 0502-000244 TR-POWER;KSA940,PNP,1.5W,TO-220,-,40-14
QG03 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6
R102 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R103 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R105 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R106 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R202 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R203 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R204 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R205 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R206 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R207 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R208 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM
R209 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R210 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
R212 2004-000218 R-METAL;10Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R213 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
R214 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R215 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R216 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R223 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R224 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R225 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R226 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R228 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M
R231 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R232 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R234 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R235 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R236 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R237 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R238 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R241 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
R242 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3.2MM
R243 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R244 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R245 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R246 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R247 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R248 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R249 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R250 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R251 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R252 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R301 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4
R302 2004-001984 R-METAL(S);26.7Kohm,1%,1/2W,AA,TP,2.4x6.
R303 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
R304 2008-000254 R-FUSIBLE(S);0.68ohm,5%,2W,AF,TP,3.9x10m
R305 2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
R306 2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
R309 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R310 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R313 2004-001137 R-METAL;6.8Kohm,1%,1/8W,AA,TP,1.8x3.2m
R314 2004-001986 R-METAL(S);35.7Kohm,1%,1/2W,AA,TP,2.4x6.
R315 2004-004970 R-METAL(S);62Kohm,1%,1/8W,AA,TP,1.8x3.2m
R401 2003-002008 R-METAL OXIDE(S);18Kohm,5%,2W,AF,TP,3.9x
R402 2003-002008 R-METAL OXIDE(S);18Kohm,5%,2W,AF,TP,3.9x
R403 2003-001091 R-METAL OXIDE(S);10ohm,5%,2W,AF,TP,4x12m
R404 2001-001038 R-CARBON(S);0.56OHM,5%,1/2W,AA,TP,2.4X6.
R405 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
R409 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
R410 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
R411 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M
R413 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10
R414 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
Electrical Parts List
