Samsung CS29A6WT8X/BWT - Page 45

R415 2004-001402 R-METAL(S);6.8Kohm,1%,1/2W,AA,TP,2.4x6.4
R417 2004-001382 R-METAL(S);13Kohm,1%,1/2W,AA,TP,2.4x6.4m
R418 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
R420 2004-001402 R-METAL(S);6.8Kohm,1%,1/2W,AA,TP,2.4x6.4
R421 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
R422 2003-000649 R-METAL OXIDE(S);330ohm,5%,1W,AF,TP,3.3x
R423 2003-001042 R-METAL OXIDE(S);5.6Kohm,5%,2W,AF,TP,3.9
R424 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10
R425 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10
R426 2003-000540 R-METAL OXIDE(S);1Kohm,5%,2W,AF,TP,4x12m
R428 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
R429 2001-001139 R-CARBON(S);39KOHM,5%,1/2W,AA,TP,2.4X6.4
R432 2001-001122 R-CARBON(S);3.9KOHM,5%,1/2W,AA,TP,2.4X6.
R433 2003-001042 R-METAL OXIDE(S);5.6Kohm,5%,2W,AF,TP,3.9
R434 2003-000664 R-METAL OXIDE(S);33ohm,5%,2W,AF,TP,4x12m
R436 2003-002008 R-METAL OXIDE(S);18Kohm,5%,2W,AF,TP,3.9x
R501 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R502 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
R503 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
R504 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R505 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
R506 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R507 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
R508 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
R509 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R510 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
R511 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R512 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
R513 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA,TP,2.4X6.
R515 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
R517 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4
R518 2003-002171 R-METAL OXIDE(S);150ohm,5%,2W,AG,TP,3.9x
R519 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7
R521 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R522 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R526 2004-000500 R-METAL;2.7Kohm,1%,1/8W,AA,TP,1.8x3.2m
R527 2004-000433 R-METAL;1Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R539 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R542 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R543 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R544 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R546 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R601 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R602 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R603 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R604 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R605 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R607 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R608 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R612 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R613 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R614 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R616 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R617 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R621 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R622 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R627 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R628 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R629 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R702 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R706 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R707 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R708 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R709 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM
R710 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM
R711 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R712 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R715 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R716 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R717 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R718 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R723 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R724 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R725 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R726 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R802 2003-001025 R-METAL OXIDE(S);15Kohm,5%,2W,AF,TP,3.9x
R803 2003-001025 R-METAL OXIDE(S);15Kohm,5%,2W,AF,TP,3.9x
R804 2003-001025 R-METAL OXIDE(S);15Kohm,5%,2W,AF,TP,3.9x
R805 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
R806 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
R807 2006-001083 R-CEMENT;120ohm,5%,5W,CJ,TP,14x10x27mm
R808 2001-001079 R-CARBON(S);15OHM,5%,1/2W,AA,TP,2.4X6.4M
R809 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M
R810 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4
R811 2004-001408 R-METAL(S);91Kohm,1%,1/2W,AA,TP,2.4x6.4m
R812 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R813 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
R816 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R817 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R818 2001-001113 R-CARBON(S);270KOHM,5%,1/2W,AA,TP,2.4X6.
R819 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6.
R820 2001-001096 R-CARBON(S);2.2OHM,5%,1/2W,AA,TP,2.4X6.4
R821 2004-001891 R-METAL(S);133Kohm,1%,1/2W,AA,TP,2.5x6.5
R822 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
R823 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R824 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
R825 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA,TP,2.4X6.4
R827 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M
R828 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
R829 2008-001029 R-FUSIBLE(S);5.6OHM,5%,2W,AF,TP,3.9X10MM
R831 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R832 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
R833 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R835 2003-002181 R-METAL OXIDE(S);68Kohm,5%,2W,AG,TP,3.9x
R836 2003-002181 R-METAL OXIDE(S);68Kohm,5%,2W,AG,TP,3.9x
R901 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R903 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R904 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R905 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R910 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R911 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R912 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
R914 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R919 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R920 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R921 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R922 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
R923 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
R924 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R925 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R927 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R928 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R929 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R930 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R931 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R932 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R933 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R934 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R935 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R936 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R937 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R938 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R943 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R945 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R946 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R947 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
7-12 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
