R948 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
RF02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF03 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
RF04 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF05 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RF06 2001-000989 R-CARBON;820KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF07 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM
RF08 2001-000313 R-CARBON;11KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RF09 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF10 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF11 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF12 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RF13 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
RF14 2001-001071 R-CARBON(S);12KOHM,5%,1/2W,AA,TP,2.4X6.4
RF15 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RF16 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
RF17 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RF18 2003-000458 R-METAL OXIDE(S);100ohm,5%,2W,AF,TP,4x12
RF19 2003-001023 R-METAL OXIDE(S);120ohm,5%,2W,AF,TP,3.9x
RF20 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
RF21 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
RF22 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x
RF23 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
RF24 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
RF25 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
RG01 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4
RG02 2004-002022 R-METAL(S);51Kohm,1%,1/2W,AA,TP,2.4x6.4m
RG03 2004-001987 R-METAL(S);4.3Kohm,1%,1/2W,AA,TP,2.4x6.4
RG04 2004-002022 R-METAL(S);51Kohm,1%,1/2W,AA,TP,2.4x6.4m
RG05 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
RG06 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RG07 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
RG08 2001-001163 R-CARBON(S);560OHM,5%,1/2W,AA,TP,2.4X6.4
RL801S 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS,
RR430S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
RX801S 2002-001010 R-COMPOSITION;1.8Mohm,5%,1/2W,AA,TP,3.7x
RY801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x
RY802S 2002-001013 R-COMPOSITION;4.7Mohm,5%,1/2W,AA,TP,3.7x
SG501 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
SG502 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
SG503 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
SG504 AA27-00084ACOIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
T401 AA26-50001L TRANS-HORIZ.DRIVE;-,29mH,133uH,4.5uH,EI2
TU01S AA40-00060ATUNER-F/S;TCPS3001PD09D(S),-,PAL-M(NTSC)
VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13PF,
X601 2801-003903 CRYSTAL-UNIT;18.432MHz,25ppm,28-AAM,12pF
X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28-AAM,20pF,40oh
ASSY CABINET FRONT
* AA90-00228XASSY CABINET;29A6,CS29A6WT8X/BWT
* AA91-00420GASSY CABINET FRONT;-,29A6 KS3A,(SPK)S704
AV+CF 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZPC(BLK),SWR
BRAC+C 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
CABBAC AA63-60001XSPACER-FELT;FELT,T0.5,BLK,330X15,-,-
CB+CF 6003-001025 SCREW-TAPTITE;RH,+,B,M4,L20,ZPC(BLK),SWR
CB+TER 6003-001025 SCREW-TAPTITE;RH,+,B,M4,L20,ZPC(BLK),SWR
CRT+CF AA60-10050VSCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S
CTS+CB 6003-001025 SCREW-TAPTITE;RH,+,B,M4,L20,ZPC(BLK),SWR
DOMESP AA60-10050ASCREW-ASSY;WP,RH,+,M4,L25,SWRCH18A,-,ZPC
KCON+C 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
LED+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
PCB+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL)
SPKR+C 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR
TER+RJ 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR
AA61-10054ABRACKET-CRATER;-,6277,STS304,T0.5,-,-,-
AA63-00005CCOVER-TOP,SPEAKER;-,72A6,-,HIPS,V2,BLK,-
AA63-60004GSPACER-GUM,CRT;NTR RUBBER,T3.0,GRY,-,-,-
AA64-00027CCABINET-BACK;-,72A6,-,HIPS,V2,BLK,-,-
AA64-01230BINLAY-COVER;D2,D3,PVC-SHEET,T0.4,94V0,-,
AA65-30008ACLAMP-CORD;PE,HB,BLK,-,-,-
AA65-30017ACLAMP-D,COIL;NYLON-66,V0,NTR,DADH300,25
AA65-30113ACLAMP-D,COIL;NYLON 66,V2,BLK,TVI 25~29,-
AA61-60003J SPRING-CS;-,SUS304,0.5,OD6,H12,N7,-,-,-
AA64-00028AKNOB-CONTROL;-,29A6,SV808P+W971,ABS,HB,G
AA64-01222CCABINET FRONT;29A6 KS3A PLANO,S704+B702
AA64-10792BKNOB-POWER;-,29A6,NO-SILK SV704P+W971 ,A
AA64-40516BWINDOW-REMOCON;-,29A6,-,PC,V0,VIOLET,-
AA64-40517BINDICATOR-LED;-,-,-,ACRYL,-,CLEAR,-
AA64-60445RINLAY AV;72A6,KS3A 100Hz,PS SHEET,-,BLK
AA64-60446CINLAY—PC,JACK;29A6,L/GRAY,PS SHEET,T0.5
AA64-70117BBADGE-BRAND;AL,SS,SILVER,L65,R2000,-,-
AA65-00011CCLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M
AA91-00335AASSY HOLDER SPK;-,PP,8ohm/15W,blk,housin
ASSY TERMINAL BOARD
* AA91-00303AASSY TERMINAL BOARD;-,HIPS,VO,BLK,KS3A S
AA63-00164BTERMINAL-BOARD,ANT;-,HIPS VO BLK,-,D3,32
AA64-00894BINLAY BACK;D2,D3,SCART(2),PS SHEET,T0.3,
ASSY HOLDER SPK
* AA91-00334BASSY HOLDER SPK;-,PP,8ohm/15W,BLK,AA91-0
ASSY CHASSIS PART
* AA90-00063CASSY CHASSIS PART;KS3A,29A6
AA61-20270AHOLDER-CHASSIS;-,CT3456V,HIPS,V0,GRY,-
MAIN 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
HOLDER 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
D-FOCU 6003-001023 SCREW-TAPTITE;RWH,+,B,M3,L10,ZPC(YEL),SW
TER+HC 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL)
AV AA65-00011CCLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M
ASSY ACCESSORY
* AA94-02493AASSY ACCESSORY;-,KS1A,-
AA39-40001BCABLE-RCA;-,RCA,1500mm,0.12/10,RED/WHT/Y
AA68-01011AMANUAL USERS;-,-,RUS(BWT),40P,-,W/P100(G
AA68-01120AMANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/
ASSY-CRT
* AA94-50022DASSY-CRT;A68QCP891X001,+380MG,29,ITC,C
AA03-00075ACRT-COLOR;-,A68QCP891X003(C),+380MG,29IN
ASSY PCB CONTROL
* AA95-00558AASSY PCB CONTROL;-,KS3A,29A6,-
CN811 AA39-20179ALEAD CONNECTOR-ASSY;-,-,-,3(2)P,-,-,-,YF
CNY01 AA39-20546CLEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB
CNY02 AA39-00106ALEAD CONNECTOR-ASSY;-,-,-,4P,-,-,-,YBNH2
CY01 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
DZY01 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500
LDY01 AA96-30003AASSY-LED,GUIDE;-,AA61-50106A,DL-G8RGA,RE
PCB AA41-00154APCB-CONTROL;KS3A,1L,FR-1,245x245x1.6T,4A
RMY01 AA59-60001UMODULE-REMOCON;-,ORC-50VF/SR-12V,38KHz,9
RY01 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M
RY02 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RY03 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RY04 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
RY05 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM
RY06 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
Samsung Electronics 7-13
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
