Samsung CS29A6WT8X/BWT - Page 47

SW811S 3403-000179 SWITCH-PUSH;250V,5A,DPST,-,JPW-2104B
SWY01 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SWY02 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SWY03 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SWY04 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SWY05 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SWY06 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
ASSY-PCB,A/V SIDE
* AA95-00682AASSY-PCB,A/V SIDE;-,29A6,29A5,KS3A,PAL,-
C701 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C702 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C703 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C704 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C705 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C706 2401-002009 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C707 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
C708 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
CN701 AA39-20068GLEAD CONNECTOR-ASSY;-,YBNH025-08,67096-0
CN702 AA39-20070JLEAD CONNECTOR-ASSY;-,-,-,7P,-,-,-,YBNH2
CN703 AA39-20069ALEAD CONNECTOR-ASSY;-,YBNH025-05,67096-0
CN704 AA39-00070ALEAD CONNECTOR-ASSY;-,-,-,-,-,-,-,-,-,YB
CN705 AA39-20009ELEAD CONNECTOR-ASSY;-,YFH800-01,-,1P,600
JA701 3722-001031 JACK-RCA;3P,3.6MM,#18,AU
JH701 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO
JS701 3722-001163 JACK-VHS;4P,12mm,AU,BLK,N
L701 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L702 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L703 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L704 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L705 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L706 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm
L707 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
L708 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
PCB AA41-00155APCB-SIDE AV;KS3A,1L,FR-1,245x245x1.6T,8A
R701 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
R702 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4
R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
ASSY-POWER,CORD
* AA96-20130CASSY-POWER,CORD;-,CP2/NO(4.0R),H/C300MM,
AA61-20284AHOLDER;-,P-CORD,PP,VO,BLK,KE-002
AA39-10003BPOWER-CORD;-,KJP-140,KLCE-2F,2.4m,HOUS,S
REMOCON
* AA59-00104AREMOCON;-,TM59,DREAM,29,L/GRAY,-,EX,PA
Electrical Parts List
7-14 Samsung Electronics
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
