Close Main
Water pipe
Close Main
Water pipe
NO GAP
4. After connecting the water supply to the water filter, turn your main water supply back on and
dispense about 3L to clear and prime the water filter.
Connecting the water line to the refrigerator
1. Remove the cap from water line on the unit and insert compression nut to the water line on the
unit after disassembling from provided water line.
2. Connect both water line from the unit and water line in the kit.
3.
Tighten the compression nut onto the compression fitting. There should be no gaps between
(A, B & C )
4. Turn water on and check for any leakage.
Loosen a
Remove
cap
Water Line
from unit
No gap
Water Line
from unit
Only connect the water line to a drinkable water source.
If you have to repair or disassemble the water line, cut off 6.5mm of the plastic tubing to make
sure you get a snug, leak-free connection.
Before being used, the leakage in these places should be examined
•
Samsung Warranty does not cover WATER LINE
INSTALLATION.
• It will be done at customer’s charge unless the retail price
includes installation cost.
• Please contact Plumber or Authorized Installer for the installation
if needed.
• If Water leakage occurs due to improper installation, Please
contact installer.
16_Setting Up
Setting up your French Door
Refrigerator
CAUTION
To Next Page
