3. Find the best level to align the door slope.
Example) The slope is about 2mm (0.08inch) as shown below.
- Rotate the Height Adjuster to +2.0 to reduce the door slope.
Slope
Reference
plane
After adjustment, tighten the screws (
2
)&(
3
) in reverse order.
CHECKING THE WATER DISPENSER LINE
A water dispenser is one of the helpful features on your new Samsung Refrigerator. To help promote
better health, the Samsung water filter removes unwanted particles from your water. However, it
does not sterilize or destroy microorganisms. You may need to purchase a water purifying system to
do that.
In order for the ice maker to operate properly, a water pressure of138~862 Kpa is required.
Under normal conditions, a 170 cc (5.75 oz.) paper cup can be filled in 10 seconds.
If the Refrigerator is installed in an area with low water pressure (below 138Kpa), you can install a
booster pump to compensate for the low pressure.
Make sure the water storage tank inside the Refrigerator is properly filled. To do this, press the water
dispenser lever until the water runs from the water outlet.
Water line installation kits are include with unit. You can find it in freezer drawer.
INSTALLING THE WATER DISPENSER LINE
1
Water line fixer
and screws
2
Pipe connector
3
Water line
4
Water Filter
Parts for water line Installation
Setting Up_15
01 SETTING UP
Connecting to the water supply line
1. First, shut off the main water supply line.
2. Locate the nearest cold, drinking water line.
3.
Follow the Water line Installation Instructions in the
installation kit.
The water line must be connected
to the cold water pipe. If it is
connected to the hot water
pipe, it may cause the purifier to
malfunction.
CAUTION
To Next Page
