1.2.2 Reverse Side
The color and shape of parts may differ from what is shown. Specifications are subject to change
without notice to improve quality.
Use this button for turning the Display on and off.
Remote sensor
Receives signals from the remote
To control the remote control in front of the product, lower the remote
control sensor in the direction of the arrow (indicated in the zoomed-in
image on the previous page).
Keep the area between the remote sensor and remote control
obstacle-free.
Port Description
[IR / AMBIENT SENSOR IN]
Supplies power to the external sensor board or receives the light
sensor signal.
[IR OUT]
Receives the remote control signal via the external sensor board and
outputs the signal via LOOPOUT.
[AUDIO OUT] Connects to the audio of a source device.
Sensor Description
