Samsung DE40A - Page 38

38
Preparations
1
1 Preparations
 RS232C cable
Connector: 9-Pin D-Sub to Stereo Cable
 Connection
-P1- -P1- -P2- -P2-
Female
Rx
Tx
Gnd
2
3
5
-------->
<--------
---------
1
2
3
Tx
Rx
Gnd
STEREO
PLUG
(3.5ø)
1
59
6
-P2-
STEREO PLUG
(3.5ø)
1
2
3
-P1-
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
