Removal and Reassembly _ 11
Part Figure Description
Console Removal
1. Disconnectthepowersupplytotheunit.
2. Removethetopcover,andthemainPCB.
3. Remove3screwsfromConsole.
4. RemovetheConsole.
5. RemovetheKnob.
6. Remove8screwsfromtheHolderPCB.
 Becarefulofexternalscratchontheconsole.
