12 _ Removal and Reassembly
Part Figure Description
Door Removal
1. Door Opening.
2. Remove2ScrewsfromtheFramepanel.
3. Separatethetemporaryxationpartofthe
assemblydoor.
4. Remove15screwsfromtheHolderGlass.
5. RemovetheDoorcover.
6. Remove8screwsfromtheSupport-Hinge.
7. RemovetheSupport-Hinge,Hinge.
8. RemovetheDoorSeal,andtheGlass.
A. Becarefulnottoscratchthedoorcover.
B. Becarefulofthedamagetothedoorglass.
C. Checkthedoorsealconditionafterthe
assembly.
