 Centrifugal Switch (Motor)
 GAS MODEL
Radiant Sensor(10RS)
• Resistancevalue<1Ω
• Ifresistanceisinnite,replaceRadiantsensor
120V
Igniter(101D)
• Resistancevalue40~400Ω
• Ifresistanceisinnite,replaceIgniter
120V4.5A
Gas Valve(25M01A)
• Valve1-2:Resistancevalue1.2KΩ
• Valve1-3:Resistancevalue0.5KΩ
• Valve4-5:Resistancevalue1.2KΩ
• Ifresistanceisinnity,replaceValve
120V60Hz,120A
Thermostat (60T21 Hi-Limit)230F-50F
• Resistancevalue<1Ω
• Ifresistanceisinnity,replaceThermostat
120V20A(60T2)
2.88Ωbetween
Pin# 3 and 4
3.5Ωbetween
Pin# 4 and 5
