36 _ Troubleshooting
 Sensor Bars & temperature sensor check
Sensor Bars
DisconnectharnessandtestPinkwirePin4toOrangewirePin5.
• Approx∞Ωwithoutlaundry
• Approx190Ω±10%withwetclothes
Cycling Thermostat
DisconnectharnessandtestBluewirePin2toRedwirePin6.
• Approx10KΩat25°C/77°F
CN6
6 1
