Exploded views and Parts list _ 67
MODEL CODE: DV220AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Code No. Description Specication Install. Point QTY Un SA/SNA
6002-001320 SCREW-TAPPING TH,+,2S,M4,L8,PASS,STS304,- COVER-
FILTER(CENTER)
1 PC SA
6002-001320 SCREW-TAPPING TH,+,2S,M4,L8,PASS,STS304,- COVER-LAMP+D/
FRONT
1 PC SA
6006-001170 SCREW-TAPPING TH,+,WT,TC,M4,L10,ZPC(WHT),SW
RCH18A,-
BOTTOM(EARTH) 1 PC SA
6009-001317 SCREW-SPECIAL CH,+,-,M4,L10,ZPC(WHT),SWRCH1
8A,FP,TAPTITE
ASSY FRAME CASE 2 PC SA
6009-001476 SCREW-HEX HEX,+,M5,L10,ZPC(WHT),SWRCH
18A,2
COVER-TOP+B/C/TOP 2 PC SA
DC61-02509A GUIDE-LED(D) WF210,HIPS,T1.5,W111,L34,BLK,BI
GBANG-PJT
GUIDE-LED(D) 1 PC SA
DC61-02541A GUIDE-LED(O) WF210,
HIPS,T1.5,W14,L68.5,BLK(SC-
06057R),BIGBANG-PJT
GUIDE-LED(O) 1 PC SA
DC63-10001C SPONGE-EPDM -,EPDM,-
,T3.0,W15,L350,BLK,OJC3000
ASSY FRAME
PLATE(U)
1 PC SA
DC63-10001J SPONGE-EPDM EPDM,BLK,SDW-
801SW,T3XW15XL100,
ASSY FRAME
PLATE(U)
1 PC SA
DC63-10001J SPONGE-EPDM EPDM,BLK,SDW-
801SW,T3XW15XL100,
FRAME(TERMINAL) 2 PC SA
DC64-02069C INLAY-PANEL DV220/BIGBANG-PJT,PET,T
0.188,W109.6,L58.1,BLK(SC-
06057R),DRYER
GUIDE-LED(D) 1 PC SA
DC64-02080A INLAY-ENCODER WF210,PET,T0.188,W85.6,L68.6,BL
ACK(SC-06057R),BIGBANG-PJT
BRACKET ENCODER 1 PC SA
DC97-15847A ASSY SCREW ACE-PJT,DV419AEU,
SWRCH18A,M4*L12
F/FRONT+D/FRONT 2 PC SA
