68 _ Exploded views and Parts list
MODEL CODE: DV220AGW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Code No. Description Specication Install. Point QTY Un SA/SNA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW1 1 PC SA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW10 1 PC SA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW2 1 PC SA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW3 1 PC SA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW4 1 PC SA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW5 1 PC SA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW6 1 PC SA
3404-001354 SWITCH-TACT 12VDC,50mA,200gf,8x13mm,SPST SW8 1 PC SA
3711-007365 CONNECTOR-
HEADER
BOX,8P,
1R,2.5mm,STRAIGHT,SN,WHT
CN2 1 PC SA
6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
BOTTOM+BRKT-
MOTOR
2 PC SA
6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
D.CON+DUCT-OUTLET 1 PC SA
6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
D/CONNEC.+C/DUCT 2 PC SA
6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
D/FRONT+DUCT-
OUTLET
2 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
HOLDER-PCB+M.PCB 1 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
F/FRONT+B/HINGE 1 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
BOTTOM+BRK-LEG 4 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
C/BACK+EXHAUST 1 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
FRAME+COVER-BACK 3 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
D/BACK+BRKT-D/B(S) 4 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
D/BACK+BRKT-D/B(T) 2 PC SA
6002-000239 SCREW-TAPPING TH,+,-
,2S,M4,L8,ZPC(WHT),SWRCH18A,-
D/BACK+DUCT-AIR 3 PC SA
6002-000241 SCREW-TAPPING TH,+,-,2S,M5,
L12,ZPC(WHT),SWRCH18A,-
HINGE-DOOR 1 PC SA
6002-000445 SCREW-TAPPING TH,+,2,M4,L18,PASS,STS304 C/FILTER(B)+D/FRONT 2 PC SA
6002-000470 SCREW-TAPPING TH,+,-
,1,M4,L10,ZPC(WHT),SWRCH18A,-
D/CONNEC.+C/DUCT 2 PC SA
6002-000470 SCREW-TAPPING TH,+,-
,1,M4,L10,ZPC(WHT),SWRCH18A,-
THERMISTOR+G/DUCT 2 PC SA
