Exploded view and parts list
8-8 Copyright ⓒ 1995-2012 SAMSUNG. All rights reserved.
Loc. No Parts No. Description Q ty Available Remark
6-1
AD64-03543A DECO RING-FRONT_BK 1 O BLACK
AD64-03658A DECO RING-FRONT_SL 1 O SILVER
6-2 AD63-04522A T/SHEET-FRONT 2 X
6-3
AD63-06509A BARRIER-PANEL_BK 1 X BLACK
AD63-06808A BARRIER-PANEL_SL 1 X SILVER
6-4
AD63-06511A BARRIER-BLADE_BK 2 X BLACK
AD63-06803A BARRIER-BLADE_SL 2 X SILVER
6-5 AD63-06510A BARRIER-LEVER 1 X
6-6 6107-003160 SPRING-ES 2 x
6-7 6107-003161 SPRING-ES 1 X
6-8 AD67-02335A LENS-G1 1 X
6-9 AD67-02336A LENS-G2 1 X
6-10 AD67-02358A BARREL-1ST 1 X
6-11 AD67-02361A BARREL-SLIPRING 1 X
6-12 AD67-02362A BARREL-ZOOMRING 1 X
6-13 AD66-00985A SHAFT-ZOOMRING PIN 3 X
6-14 AD67-02364A BARREL-INNER CAM 1 O
6-15 AD61-05495A PLATE-INNER GUIDE 1 O
6-16
AD64-03544A DECO RING-CAM_BK 1 X BLACK
AD64-03654A DECO RING-CAM_SL 1 X SILVER
6-17 AD63-06796A SHIELD-CAM 1 X
6-18 AD67-02363A BARREL-OUTER CAM 1 X
6-19 AD67-02365A BARREL-OUTER GUIDE 1 O
6-20 AD67-02366A BARREL-BASE 1 O
6-21 AD81-04801A A/S-MAIN PCB TAPE 1 X
6-22 AD63-06512A SHEET-G3 1 X
6-23 AD67-02339A LENS ASP LENS-G3 1 X
6-24 AD67-02337A LENS-G4 1 X
6-25 AD67-02338A LENS 1 X
6-26 AD67-02359A BARREL-2ND 1 X
6-27 AD63-06513A SHEET-G5 1 X
6-28 AD97-21682A ASSY SHUTTER-OIS 1 X
6-29 AD67-02340A LENS ASP LENS-G6 1 X
6-30 AD67-02360A BARREL-3RD 1 X
6-31 6107-003159 SPRING-ES 1 X
6-32 AD66-00984A SHAFT-AF GUIDE 1 X
6-33 AD61-05494A BASE-LENS 1 X
6-34 AD94-00250A ASSY SMD INSERT-OIS 1 X
