Samsung DV5451AEW - Standard Disassembly Drawings; Panel Control Removal

10 _ Disassembly and Reassembly
3-2. STANDARD DISASSEMBLY DRAWINGS
To avoid risk of electrical shock, personal injury or death, disconnect the power to the Clothes Dryer.
► Thisisastandarddisassemblydiagramandmaydifferfromtheactualproduct.
Usethismaterialasareferencewhendisassemblingandreassemblingtheproduct.
Part Figure Description
Panel Control
Removal
1. Disconnectthepowersupplytotheunit.
2. Remove4screwsfromtheCoverPanel.
3. RemovethePanelControl.
4. RemoveEachHousing.
5. RemovetheKnob.
6. Remove4screwsfromtheHolderPCB.
 BecarefulofexternalscratchonthePanel
Control.
