Samsung DV5451AEW - Gas Dryer Power Supply; Proper Grounding and Polarization for 120 Volts Wall Outlets

4 _ Safety Instructions
■ Gas dryer power supply
ThisequipmentMUSTbegrounded.Intheeventofanelectricalshortcircuit,groundingreducestheriskofelectricshock
byprovidinganescapewirefortheelectricalcurrent.Thisunitisequippedwithacordhavingagroundingwirewitha
groundingplug.Theplugmustbepluggedintoanoutletthatisproperlyinstalledandgrounded.
Consultaqualiedelectricianorservicerifgroundinginstructionsarenotcompletelyunderstood,orifdoubtexistsasto
whethertheequipmentisproperlygrounded.
Donotuseanextensioncord.Iftheproductpowercordistooshort,haveaqualiedelectricianinstallathreeslot
receptacle.Thisunitshouldbepluggedintoaseparate60hertzcircuitwiththeelectricalratingasshownontheserial
plate.
■ Proper grounding and polarization for 120 volts wall outlets
ForthesafetyofourcustomersandtheservicetechnicianALLgas
dryershaveathree-prongpowercordandMUSTbeconnectedtoa
properlypolarizedandgroundedwalloutlet.Thisinformationwaswritten
forthosewhodonotunderstandgroundingandpolarizationofawall
outlet.A120VACwalloutletmustalwaysbewiredasshownright.
Polarization -Thismeansthatthelargerslotmustbeneutralandthe
smallslotmustbehot(live).
Mispolarized -Theoutletismiswiredsothatthelargerslotishot(live)
andthesmallerslotisneutral.
Grounded -Thismeanstheroundholeconnectionisconnectedto
groundthroughaconnectiontothemainpowerpanel.
Ungrounded -Theroundholeconnectionisnotconnectedtoaground
and/orthemainpowerpanel.
WARNING
Toavoiddeath,personalinjuryorpropertydamage,fromreorexplosion,informationinthismanualmustbefollowed
exactly.
Donotstoreorusegasolineorotherammablevaporsandliquidsinthevicinityofthisoranyotherappliance.
WHAT TO DO IF YOU SMELL GAS
- Donottrytolightanyappliance.
- Donottouchanyelectricalswitch;donotuseanyphoneinyourbuilding.
- Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegassupplier’sinstructions.
- Ifyoucannotreachyourgassupplier,calltheredepartment.Installationandservicemustbeperformedbya
qualiedinstaller,serviceagencyorthegassupplier.
WARNING
Toreducetheriskofreandexposuretocombustiongases,thedryerMUSTbeexhaustedtotheoutdoors.
DONOTexhaustdryerairintoawindowwell,gasvent,chimneyorenclosed,unventilatedarea,suchasanattic,wall,
ceiling,crawlspaceunderabuildingorconcealedspaceofabuilding.
Neutralside
Round grounding
prong
Ground
L1
Neutral
0
V.A.C.
115±15
V.A.C.
115±12
V.A.C.
