Samsung DV5451AEW - Assy Motor Removal

18 _ Disassembly and Reassembly
Part Figure Description
Assy Motor Removal
(Continued)
1. Disconnectthepowersupplytotheunit.
2. RemovethePanelControl,theMainPCB,the
CoverTop,theFrameFront,theDrumFrontand
theDrum.
3. Remove2screwsfromtheDuctConnector.
4. Remove 1 Housing Motor.
5. Remove1HousingBeltCutOffSwitch.
6. Remove3screwsfromtheMotor-Bracket.
