Samsung DV5451AEW - Duct Exhaust Removal

22 _ Disassembly and Reassembly
Part Figure Description
Drum Back Removal
7. RemovetheterminalsfromtheValve-Water.
8.Remove4screwsfromtheAirDuct.
 Becarefuloftheframeedge.
Duct Exhaust
Removal
1. Disconnectthepowersupplytotheunit.
2. Remove1screwsfromtheBack-Cover.
3. Remove1screwfromtheDuct-Exhaust.
Incasethescrewsforxingapowercodeare
droppedintothedryer,afterremovingDuct
Exhaust,youcanputitoutthroughthehole.
