10 _ Disassembly and Reassembly
Part Figure Description
Frame Front
Removal
1. Disconnectthepowersupplytotheunit.
2. RemovethePanelControl,theMainPCBandthe
Cover Top.
3. Remove3screwsfromtheFrameFront.
 When1screwsofthetopportionworkbecause
wasaddednewly,keepinmind.
5. Remove3screws.
6. RemovetheDoorSwitchHousing.
 WhenreassembleDoorSwitchtoFrameFront,
becarefulforinsertdirection.
7. LifttheFrameFrontoffthethreetabsacrossthe
bottomandremove.
复件 Hudson_Dryer_SM_E.indb 14 2012-4-2 15:20:50
