Disassembly and Reassembly _ 9
Part Figure Description
DOOR REVERSAL
< Figure. 1 >
< Figure. 2 >
10.Removetheholder-glass.
11.Exchangethepositionsof:
:Thecover-hingeandhandledoor
:Theholder-hingeandguiderholderglass
12.RemovetheLever-Door,Cover-Lever(DV400
Only)andtheninstallitontheoppositeside.
:DV456&DV422ReferFigure.1
:DV400ReferFigure.2
Refertotheillustrationsontherighttoaidyou
intheassemblyprocess.
13.Removethecover-hole(P1).
14.Assembletheholderglassandthenfastenthe14
screwsthatyouremovedinstep9.
15.Attachthecover-hole.
Asparecoverholeisintheassymanual.
16.Installthedoorontheframe-frontandthenfasten
the4screwsthatyouremovedinstep2.
Checkthepositionsofthescrewsyouinstalled
inthehingedoor
