10 _ Disassembly and Reassembly

Part Figure Description

DOOR REVERSAL

(Continued)

1. Unplugthepowercord.

2. Removethefourhingescrewsfromthedoor.

3. Removethedoorbyliftingit.

4. Removethetwoscrewsfromtheholder-lever,and

thenremovethecover-holder.

5. Assembletheholder-leverontheoppositeside

usingthescrewsthatwereremovedfromthe

holder-lever-inStep4.

6. Assemblethecover-holderontheoppositeside.

7. Removethetwocover-hinges.

8. Assemblethetwocover-hingesontheopposite

side.

Useaatheadscrewdriver(-)toremovethe

cover-holder’scover-hinge.

9. Removethe14screws.

2screw(L)arelongerthantheotherscrews.
