Samsung DVM S AM MXVAFC Series User Manual

12
Preparing for installation
Model name for combination AM180MXVAFCAAZ AM200MXVAFCAAZ AM220MXVAFC3AZ AM240MXVAFC3AZ AM260MXVAFC3AZ
Number of individual outdoor units 11222
Combined outdoor unit
AM080MXVAFC
AM100MXVAFC 1
AM120MXVAFC 121
AM140MXVAFC 1
AM160MXVAFC
AM180MXVAFC 1
AM200MXVAFC 1
Nominal capacity
Cooling (kW) 50.4 56.0 61.6 67.2 73.6
Cooling (Btu/h) 172 000 191 100 210 100 229 200 251 100
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 25.2 28.0 30.8 33.6 36.8
Minimum (Btu/h) 86 000 95 500 105 100 114 600 125 500
Maximum (kW) 65.5 72.8 80.1 87.4 95.7
Maximum (Btu/h) 223 600 248 400 273 200 298 000 326 400
Maximum number of connectable indoor
units
32 36 40 43 47
Model name for combination AM280MXVAFC3AZ AM300MXVAFC3AZ AM320MXVAFC3AZ AM340MXVAFC3AZ AM360MXVAFC3AZ
Number of individual outdoor units 22222
Combined outdoor unit
AM080MXVAFC
AM100MXVAFC
AM120MXVAFC 111
AM140MXVAFC 1
AM160MXVAFC 11
AM180MXVAFC 1
AM200MXVAFC 111
Nominal capacity
Cooling (kW) 78.6 84.0 89.6 96.0 101.0
Cooling (Btu/h) 268 100 286 600 305 700 327 600 344 600
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 39.3 42.0 44.8 48.0 50.5
Minimum (Btu/h) 134 100 143 300 152 800 163 700 172 300
Maximum (kW) 102.2 109.2 116.5 124.8 131.3
Maximum (Btu/h) 348 600 372 600 397 400 422 300 448 000
Maximum number of connectable indoor
units
51 54 58 61 64
