Preparing for installation
Model name for combination AM580MXVAFC3AZ AM600MXVAFC3AZ AM620MXVAFC3AZ AM640MXVAFC3AZ
Number of individual outdoor units 3344
Combined outdoor unit
AM080MXVAFC
AM100MXVAFC 1
AM120MXVAFC 12
AM140MXVAFC
AM160MXVAFC
AM180MXVAFC 1
AM200MXVAFC 2322
Nominal capacity
Cooling (kW) 162.4 168.0 173.6 179.2
Cooling (Btu/h) 554 200 573 300 592 300 611 400
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 81.2 84.0 86.8 89.6
Minimum (Btu/h) 277 000 286 500 296 200 305 600
Maximum (kW) 211.1 218.4 225.7 233.0
Maximum (Btu/h) 720 400 745 200 770 000 794 800
Maximum number of connectable indoor
units
64 64 64 64
Model name for combination AM660MXVAFC3AZ AM680MXVAFC3AZ AM700MXVAFC3AZ AM720MXVAFC3AZ
Number of individual outdoor units 4444
Combined outdoor unit
AM080MXVAFC
AM100MXVAFC
AM120MXVAFC 1111
AM140MXVAFC 1
AM160MXVAFC 1
AM180MXVAFC 1
AM200MXVAFC 2223
Nominal capacity
Cooling (kW) 185.6 190.6 196.0 201.6
Cooling (Btu/h) 633 300 650 300 668 800 687 900
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 92.8 95.3 98.0 100.8
Minimum (Btu/h) 316 500 325 100 334 300 343 800
Maximum (kW) 241.3 247.8 254.8 262.1
Maximum (Btu/h) 823 200 845 400 869 400 894 200
Maximum number of connectable indoor
units
64 64 64 64
