Samsung DVM S AM MXVAFC Series User Manual

16
Preparing for installation
Model name for combination AM180MXVAFC/AZ AM200MXVAFC/AZ AM220MXVAFC/AZ AM240MXVAFC/AZ AM260MXVAFC/AZ
Number of individual outdoor units 11111
Combined outdoor unit
AM080MXVAFC
AM100MXVAFC
AM120MXVAFC
AM140MXVAFC
AM160MXVAFC
AM180MXVAFC 1
AM200MXVAFC 1
AM220MXVAFC 1
AM240MXVAFC 1
AM260MXVAFC 1
Nominal capacity
Cooling (kW) 50.4 56.0 61.6 67.2 72.8
Cooling (Btu/h) 172 000 191 100 210 200 229 300 248 400
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 25.2 28.0 30.8 33.6 36.4
Minimum (Btu/h) 86 000 95 500 105 100 114 600 124 200
Maximum (kW) 65.5 72.8 80.1 87.4 94.6
Maximum (Btu/h) 223 600 248 400 273 200 298 100 322 900
Maximum number of connectable indoor
units
32 36 40 43 47
Model name for combination AM280MXVAFC2AZ AM300MXVAFC2AZ AM320MXVAFC2AZ AM340MXVAFC2AZ AM360MXVAFC2AZ
Number of individual outdoor units 22222
Combined outdoor unit
AM080MXVAFC 11
AM100MXVAFC 11
AM120MXVAFC 1
AM140MXVAFC
AM160MXVAFC 1
AM180MXVAFC
AM200MXVAFC 1
AM220MXVAFC
AM240MXVAFC 1
AM260MXVAFC 11
Nominal capacity
Cooling (kW) 78.6 84.0 89.6 95.2 100.8
Cooling (Btu/h) 268 100 286 600 305 700 324 800 343 900
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 39.3 42.0 44.8 47.6 50.4
Minimum (Btu/h) 134 100 143 300 152 900 162 400 172 000
Maximum (kW) 102.2 109.2 116.5 123.8 131.0
Maximum (Btu/h) 348 600 372 600 397 400 422 200 447 100
Maximum number of connectable indoor
units
51 54 58 61 64
