Preparing for installation
Model name for combination AM580MXVAFC2AZ AM600MXVAFC2AZ AM620MXVAFC2AZ AM640MXVAFC2AZ
Number of individual outdoor units 3333
Combined outdoor unit
AM080MXVAFC 11
AM100MXVAFC 1
AM120MXVAFC 1
AM140MXVAFC
AM160MXVAFC
AM180MXVAFC
AM200MXVAFC
AM220MXVAFC
AM240MXVAFC 1
AM260MXVAFC 1222
Nominal capacity
Cooling (kW) 162.4 168.0 173.6 179.2
Cooling (Btu/h) 554 100 573 200 592 300 611 400
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 81.2 84.0 86.8 89.6
Minimum (Btu/h) 277 100 286 600 296 200 305 700
Maximum (kW) 211.1 218.4 225.7 233.0
Maximum (Btu/h) 720 300 745 200 770 000 794 800
Maximum number of connectable indoor
units
64 64 64 64
Model name for combination AM660MXVAFC2AZ AM680MXVAFC2AZ AM700MXVAFC2AZ AM720MXVAFC2AZ
Number of individual outdoor units 3333
Combined outdoor unit
AM080MXVAFC
AM100MXVAFC
AM120MXVAFC
AM140MXVAFC 1
AM160MXVAFC 1
AM180MXVAFC 1
AM200MXVAFC 1
AM220MXVAFC
AM240MXVAFC
AM260MXVAFC 2222
Nominal capacity
Cooling (kW) 185.6 190.6 196.0 201.6
Cooling (Btu/h) 633 300 650 300 668 800 687 900
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 92.8 95.3 98.0 100.8
Minimum (Btu/h) 316 700 325 200 334 400 344 000
Maximum (kW) 241.3 247.8 254.8 262.1
Maximum (Btu/h) 823 300 845 400 869 400 894 300
Maximum number of connectable indoor
units
64 64 64 64
