Preparing for installation
Model name for combination AM180MXVAJC/AZ AM200MXVAJC/AZ AM220MXVAJC/AZ AM240MXVAJC/AZ AM260MXVAJC/AZ
Number of individual outdoor units 11111
Combined outdoor unit
AM080MXVAJC
AM100MXVAJC
AM120MXVAJC
AM140MXVAJC
AM160MXVAJC
AM180MXVAJC 1
AM200MXVAJC 1
AM220MXVAJC 1
AM240MXVAJC 1
AM260MXVAJC 1
AM280MXVAJC
AM300MXVAJC
Nominal capacity
Cooling (kW) 50.4 56.0 61.6 67.2 72.8
Cooling (Btu/h) 172 000 191 100 210 200 229 300 248 400
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 25.2 28.0 30.8 33.6 36.4
Minimum (Btu/h) 86 000 95 500 105 100 114 600 124 200
Maximum (kW) 65.5 72.8 80.1 87.4 94.6
Maximum (Btu/h) 223 600 248 400 273 200 298 100 322 900
Maximum number of connectable indoor
units
32 36 40 43 47
Model name for combination AM280MXVAJC/AZ AM300MXVAJC/AZ AM320MXVAJC2AZ AM340MXVAJC2AZ AM360MXVAJC2AZ
Number of individual outdoor units 11222
Combined outdoor unit
AM080MXVAJC
AM100MXVAJC 1
AM120MXVAJC 1
AM140MXVAJC 1
AM160MXVAJC
AM180MXVAJC
AM200MXVAJC
AM220MXVAJC 111
AM240MXVAJC
AM260MXVAJC
AM280MXVAJC 1
AM300MXVAJC 1
Nominal capacity
Cooling (kW) 78.6 84.0 89.6 95.2 101.6
Cooling (Btu/h) 268 200 286 600 305 700 324 800 346 700
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 39.3 42.0 44.8 47.6 50.8
Minimum (Btu/h) 134 100 143 300 152 900 162 400 173 400
Maximum (kW) 102.2 109.2 116.5 123.8 132.1
Maximum (Btu/h) 348 700 372 600 397 400 422 200 450 700
Maximum number of connectable indoor
units
51 54 58 61 64
