Preparing for installation
Model name for combination AM580MXVAJC2AZ AM600MXVAJC2AZ AM620MXVAJC2AZ AM640MXVAJC2AZ
Number of individual outdoor units 2233
Combined outdoor unit
AM080MXVAJC
AM100MXVAJC
AM120MXVAJC
1 1
AM140MXVAJC
AM160MXVAJC
AM180MXVAJC
AM200MXVAJC
AM220MXVAJC 11
AM240MXVAJC
AM260MXVAJC
AM280MXVAJC 11
AM300MXVAJC 12 1
Nominal capacity
Cooling (kW) 162.6 168.0 173.8 179.2
Cooling (Btu/h) 554 800 573 200 593 000 611 400
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 81.3 84.0 86.9 89.6
Minimum (Btu/h) 277 400 286 600 296 500 305 700
Maximum (kW) 211.4 218.4 225.9 233.0
Maximum (Btu/h) 721 200 745 200 770 900 794 800
Maximum number of connectable indoor
units
64 64 64 64
Model name for combination AM660MXVAJC2AZ AM680MXVAJC2AZ AM700MXVAJC2AZ AM720MXVAJC2AZ
Number of individual outdoor units 3333
Combined outdoor unit
AM080MXVAJC
AM100MXVAJC
AM120MXVAJC
AM140MXVAJC 1
AM160MXVAJC
AM180MXVAJC
1 1
AM200MXVAJC
AM220MXVAJC 1112
AM240MXVAJC
AM260MXVAJC
AM280MXVAJC 11
AM300MXVAJC 11
Nominal capacity
Cooling (kW) 185.6 190.6 196.0 201.8
Cooling (Btu/h) 633 300 650 400 668 800 688 600
Total capacity of the
connected indoor units
(Cooling)
Minimum (kW) 92.8 95.3 98.0 100.9
Minimum (Btu/h) 316 700 325 200 334 400 344 300
Maximum (kW) 241.3 247.8 254.8 262.3
Maximum (Btu/h) 823 300 845 500 869 400 895 200
Maximum number of connectable indoor
units
64 64 64 64
