Electrical wiring work
Selecting solderless ring terminal
f Select a solderless ring terminal for a power cable according to the nominal dimensions for cable.
f Apply insulation coating to the connection part of the solderless ring terminal and the power cable.
Silver solder
Nominal dimensions for
cable [mm
2
(inch
2
)]
4/6 (0.006/0.009) 10 (0.01) 16 (0.02) 25 (0.03) 35 (0.05) 50 (0.07) 70 (0.10)
Nominal dimensions for
screw [mm (inch)]
4 (3/8) 8 (3/16) 8 (3/16) 8 (3/16) 8 (3/16) 8 (3/16) 8 (3/16) 8 (3/16) 8 (3/16) 8 (3/16)
B
Standard
dimension
[mm (inch)]
9.5 (3/8) 15 (9/16) 15 (9/16) 16 (10/16) 12 (1/2)
16.5
(10/16)
16
(10/16)
22 (7/8) 22 (7/8) 24 (1)
Allowance
[mm (inch)]
±0.2 (±0.007)
±0.2
(±0.007)
±0.2
(±0.007)
±0.3 (±0.011) ±0.3 (±0.011)
±0.3
(±0.011)
±0.4
(±0.015)
D
Standard
dimension
[mm (inch)]
5.6 (1/4) 7.1 (1/4) 9 (3/8) 11.5 (7/16) 13.3 (1/2) 13.5 (1/2) 17.5 (1/2)
Allowance
[mm (inch)]
+0.3 (+0.011)
-0.2 (-0.007)
+0.3
(+0.011)
-0.2
(-0.007)
+0.3
(+0.011)
-0.2
(-0.007)
+0.5 (+0.019)
-0.2 (-0.007)
+0.5 (+0.019)
-0.2 (-0.007)
+0.5
(+0.019)
-0.2
(-0.007)
+0.5
(+0.019)
-0.4
(-0.015)
d1
Standard
dimension
[mm (inch)]
3.4 (1/8) 4.5 (3/16) 5.8 (1/4) 7.7 (5/16) 9.4 (3/8)
11.4
(7/16)
13.3 (1/2)
Allowance
[mm (inch)]
±0.2
(±0.007)
±0.2
(±0.007)
±0.2
(±0.007)
±0.2
(±0.007)
±0.2
(±0.007)
±0.3
(±0.011)
±0.4
(±0.015)
E Min. [mm (inch)]
6
(1/4)
7.9
(5/16)
9.5
(5/16)
11
(3/8)
12.5
(1/2)
17.5
(11/16)
18.5
(3/4)
F Min. [mm (inch)]
5
(3/16)
9
(3/8)
9
(3/8)
13
(1/2)
15
(5/8)
13
(1/2)
13
(1/2)
13
(1/2)
14
(9/16)
20
(3/4)
L Max. [mm (inch)]
20
(3/4)
28.5
(1-1/8)
30
(1-3/16)
33
(1-5/16)
34
(1-3/8)
38
(1-1/2)
43
(1-
11/16)
50
(2)
51
(2)
d2
Standard
dimension
[mm (inch)]
4.3
(3/16)
8.4
(1-3/16)
8.4
(1-3/16)
8.4
(1-3/16)
8.4
(1-3/16)
8.4
(1-3/16)
8.4
(1-3/16)
8.4
(1-3/16)
8.4
(1-3/16)
8.4
(1-3/16)
Allowance
[mm (inch)]
+ 0.2
(+0.007)
0 (0)
+ 0.4
(+0.015)
0 (0)
+ 0.4
(+0.015)
0 (0)
+ 0.4
(+0.015)
0 (0)
+ 0.4 (+0.015)
0 (0)
+ 0.4 (+0.015)
0 (0)
+ 0.4
(+0.015)
0 (0)
+ 0.4
(+0.015)
0 (0)
t Min. [mm (inch)]
0.9
(0.03)
1.15
(0.04)
1.45
(0.05)
1.7
(0.06)
1.8
(0.07)
1.8
(0.07)
2.0
(0.078)
