69
ENGLISH
Installing the Solution device
f When the number of indoor units installed with the outdoor unit is 16 or less
F1 F2 OF1 OF2 R1 R2
F1
Terminal block with indoor
unit
F2
OF1
Terminal block with
outdoor unit sub module
OF2
R1
Terminal block with
solution device
R2
