■ This appliance must be earthed.
■ This appliance is designed to be connected to a 220~240V, 50/60Hz AC electricity supply.
■ The wires in the mains lead are coloured in accordance with the following code ;
- Green/yellow = Earth
- Blue = Neutral
- Brown = Live
■ The wire which is coloured green and yellow must be connected
to the terminal which is marked with the letter E or by the earth
symbol.
Electrical Connection
■ WIRING DIAGRAM
