1.2.6 External Application Servers
The following application servers are separated in the IPX-S3000B system.
Billing Server
The billing server is a device that receives the billing information (CDR: Call Detailed
Record) that are generated from various call handling systems, extracts the billing data
needed for actual operation, and performs the tasks such as various billing related statistics
and others. IPX-S300B sends CDR that is generated after the call handling to the Billing
server by using the protocols such as TCP or FTP.
1.2.7 Interface between the Network Components
The table below describes the interface between each system component.
Area
Physical Connection
Protocol
IPX-S300B  IP Phone
LAN
SIP
IPX-S300B  Wi-Fi Phone
LAN
SIP
IPX-S300B  Soft Phone
LAN
SIP
IPX-S300B  Management
LAN
TCP
IPX-S300B  Solution Partner
LAN
SIP/CSTA/TAPI/JTAPI
IPX-S300B  Voice Gateway
LAN
SIP
IPX-S300B  Media Gateway
PRI/BRI/FXO
PRI/BRI/Loop Start
