UR19 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR2 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR20 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR21 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR22 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR23 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR24 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR25 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR26 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR27 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR28 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR29 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR3 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR31 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR32 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR33 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR34 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR35 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR36 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR38 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR40 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR41 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR42 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR48 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR49 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR5 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR50 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR51 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR52 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR53 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR54 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR55 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR56 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR57 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR58 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR59 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR6 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR60 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR61 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR62 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR63 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR64 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR65 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR7 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR73 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,1/0.5
UR74 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR8 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR80 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR86 2001-000869 R-CARBON;56OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR87 2001-000869 R-CARBON;56OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR88 2001-000869 R-CARBON;56OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR89 2001-000869 R-CARBON;56OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR9 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR95 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR96 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR97 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
UR99 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
USW1 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW10 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW11 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW12 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW13 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW14 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW15 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW16 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW17 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW18 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW19 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW2 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW20 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW3 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW4 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW5 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW6 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW7 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW8 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
USW9 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X6MM,S
AH90-10738A ASSY-MAIN PCB;MAX810,EXP,3BAND,FTZ S.N.A
AIC1 1201-000328 IC-POWER AMP;4141,SIP,18P,-,-,-,PLASTIC,
AJ1 3716-000209 TERMINAL-BLOCK;,-,-,60V,7A
AJ1-1 AH63-40009A SHIELD-PLATE;TE-SBC,T0.3,-,SCM8100L/SEG,
AJ2 3722-000363 JACK-PHONE;9P,6.4MM,AU,BLK,-
AL2L AH27-90001B COIL-SPRING;,2.2UH,-,-,SPRING
AL2R AH27-90001B COIL-SPRING;,2.2UH,-,-,SPRING
AL3L AH27-90001B COIL-SPRING;,2.2UH,-,-,SPRING
AL3R AH27-90001B COIL-SPRING;,2.2UH,-,-,SPRING
BIC1 1204-001281 IC-AUDIO PROCESSOR;TDA7439,DIP,30P,400MI
BJ1 3722-000377 JACK-RCA;4P/2C,3.5MM,SN,BLK,#16~22
DECK AH39-50001X LEAD-FASTEN;RING,1007#24,200MM,BLK
EIFT1 AH27-80060B COIL-OSC;RBQ-07VB,393UH,MW/LW-RF
FJ1 3716-000198 TERMINAL-BLOCK;NON SOLDER,3P,4MM,-,
H/SINK AH62-30126A HEAT SINK-MAIN;-,AL EXTRA,-,-,-,WHT,-,MA
HIC1 AH14-10007G IC;LC72131,DIP,STICK PLL
HX1 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12PF,30
IC 6003-000276 SCREW-TAPTITE;BH,+,B,M3,L10,ZPC(YEL),SWC
ICF1 2903-000148 FILTER-CERAMIC;BP,450KHZ+-1KHZ,-,6DB,-,B
ICF2 2802-000215 RESONATOR-CERAMIC;19KHZ,+-38HZ,-,7.0X3.5
IFT1 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450K
IFT2 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,11.32M
IIC1 AH14-10007H IC;LA1836,DIP,STICK IF+MPX
IL1 AH26-10001A TRANS-IF;FV-AD-BASE19K/38K,LOW PASS FILT
IL2 AH26-10001A TRANS-IF;FV-AD-BASE19K/38K,LOW PASS FILT
IL3 AH27-10001K COIL-CHOKE;10MH,K,Q10,-,-,CL-3,-,-,
JCW1 3711-000733 CONNECTOR-HEADER;BOX,17P,1R,2.5MM,STRAIG
JIC1 1201-000358 IC-PREAMP;22291,DIP,24P,-,DUAL,-,PLASTIC
JL1L AH26-10002Y COIL-TRAP;FB875-85A,BIAS-TRAP,35DB,8.0,1
JL1R AH26-10002Y COIL-TRAP;FB875-85A,BIAS-TRAP,35DB,8.0,1
JL3 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450K
MCW2 3710-001221 CONNECTOR-SOCKET;30P,1R,1.25MM,ANGLE,SN
P/CORD AH39-10002L POWER CORD;CP2,KLCE-2F,2.15M,5239,VDE
PL1 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,
PL2 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,
PSC1 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
PSC2 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
PSCW1 3722-000337 JACK-AC POWER;2P,-,NI,BLK,#16~22
R1R-1 3711-000733 CONNECTOR-HEADER;BOX,17P,1R,2.5MM,STRAIG
RC10 2401-000118 C-AL;1000UF,20%,10V,GP,TP,10X12.5,5
RC15 2401-001067 C-AL;3300UF,20%,42V,GP,-,18X35.5,7.
Electrical Parts List
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
8-2 Samsung Electronics
To Next Page
