RC2 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,
RC23 2401-001364 C-AL;470UF,20%,16V,GP,TP,10X12MM,5M
RC3 2401-001067 C-AL;3300UF,20%,42V,GP,-,18X35.5,7.
RC3 2401-001364 C-AL;470UF,20%,16V,GP,TP,10X12MM,5M
RC4 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,
RC5 2401-000871 C-AL;220UF,20%,50V,GP,-,10X16MM,5MM
RC6 2401-001942 C-AL;3300UF,20%,35V,GP,BK,18X35.5MM
RCON1 AH39-20514A LEAD CONNECTOR-ASSY;-,5264,51088,10P,300
RCW1 3711-000586 CONNECTOR-HEADER;BOX,10P,1R,2.5MM,ANGLE,
RCW1-1 AH39-20514A LEAD CONNECTOR-ASSY;-,5264,51088,10P,300
RCW2 3711-001137 CONNECTOR-HEADER;BOX,8P,1R,2mm,STRAIGHT,
RD2 0402-000450 DIODE-BRIDGE;PBL403,200V,4.0A,DIP-4
RD7 0402-000157 DIODE-RECTIFIER;1N5402,200V,3A,DO-201AD
RD8 0402-000157 DIODE-RECTIFIER;1N5402,200V,3A,DO-201AD
RF1 3601-000207 FUSE-FERRULE;250V,1A,TIME LAG,GLASS,5X20
RF3 3601-000248 FUSE-FERRULE;250V,2A,TIME LAG,GLASS,5X20
RF4 3601-000248 FUSE-FERRULE;250V,2A,TIME LAG,GLASS,5X20
RIC1 1203-000166 IC-POSI.ADJUST REG.;3950,SIP,12P,-,PLAST
RQ3 0502-000424 TR-POWER;2SB1566-F,PNP,2W,TO-220FN,BK,1
RR4 2003-000736 R-METAL OXIDE(S);560OHM,5%,3W,AA,TP,6X16
T-PA AH40-10001T TUNER;FE415-G11,-,75OHM
AH93-30002E ASSY-MAIN COM,AUTO;MAX810,EXP,3BAND,FTZ
S.N.A
AC10 2401-001938 C-AL;22UF,20%,25V,GP,BK,5X11MM,2MM
AC11 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
AC14 2401-002168 C-AL;100UF,20%,50V,GP,TP,10X12.5,5M
AC15 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
AC16L 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
AC16R 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
AC17L 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
AC17R 2201-000520 C-CERAMIC,DISC;4.7NF,+80-20%,400VAC,Y5V,
AC18L 2201-000783 C-CERAMIC,DISC;100NF,+80%,-20%,50V,Y5V,T
AC18R 2201-000783 C-CERAMIC,DISC;100NF,+80%,-20%,50V,Y5V,T
AC1L 2202-000806 C-CERAMIC,MLC-AXIAL;220PF,10%,50V,Y5P,TP
AC1R 2202-000806 C-CERAMIC,MLC-AXIAL;220PF,10%,50V,Y5P,TP
AC20L 2301-000469 C-FILM,PEF;68NF,10%,50V,TP,9X12X4.5MM,5M
AC20R 2301-000469 C-FILM,PEF;68NF,10%,50V,TP,9X12X4.5MM,5M
AC2L 2202-000850 C-CERAMIC,MLC-AXIAL;2.2NF,30%,16V,Y5R,TP
AC2R 2202-000850 C-CERAMIC,MLC-AXIAL;2.2NF,30%,16V,Y5R,TP
AC4L 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
AC4R 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
AC5L 2401-001895 C-AL;100UF,20%,16V,GP,BK,6.3X11MM,2
AC5R 2401-001895 C-AL;100UF,20%,16V,GP,BK,6.3X11MM,2
AC6L 2401-001552 C-AL;47UF,20%,35V,GP,-,6.3X11,2.5MM
AC6R 2401-001552 C-AL;47UF,20%,35V,GP,-,6.3X11,2.5MM
AC7 2401-001895 C-AL;100UF,20%,16V,GP,BK,6.3X11MM,2
AC7L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
AC8L 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
AC8R 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
AC9L 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
AC9R 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
AQ1L 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800MW,TO-9
AQ1R 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800MW,TO-9
AQ2 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K-22K,TO-
AQ3 0504-000121 TR-DIGITAL;KSR1007,NPN,300MW,22K-47K,TO-
AR10L 2001-001146 R-CARBON(S);4.7OHM,5%,1/2W,AA,TP,2.4X6.4
AR10R 2001-001146 R-CARBON(S);4.7OHM,5%,1/2W,AA,TP,2.4X6.4
AR11 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR11L 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4
AR11R 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4
AR12 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
AR16 2008-000121 R-FUSIBLE;100OHM,5%,1/4W,AA,TP,2.6X6.7MM
AR17 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
AR18 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
AR19 2008-000121 R-FUSIBLE;100OHM,5%,1/4W,AA,TP,2.6X6.7MM
AR1L 2001-000858 R-CARBON;56KOHM,1%,1/8W,AD,TP,1.8X3.2MM
AR1R 2001-000858 R-CARBON;56KOHM,1%,1/8W,AD,TP,1.8X3.2MM
AR20 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
AR2L 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR2R 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR3L 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR3R 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AR4L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
AR4R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
AR5L 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR5R 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
AR6L 2001-000858 R-CARBON;56KOHM,1%,1/8W,AD,TP,1.8X3.2MM
AR6R 2001-000858 R-CARBON;56KOHM,1%,1/8W,AD,TP,1.8X3.2MM
AR7L 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
AR7R 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
AR8L 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
AR8R 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6.
AR9L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
AR9R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
BC1 2202-000806 C-CERAMIC,MLC-AXIAL;220PF,10%,50V,Y5P,TP
BC10L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC10R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC11L 2202-000806 C-CERAMIC,MLC-AXIAL;220PF,10%,50V,Y5P,TP
BC11R 2202-000806 C-CERAMIC,MLC-AXIAL;220PF,10%,50V,Y5P,TP
BC14L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC14R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC15L 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,TP,
BC15R 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,TP,
BC16L 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V
BC16R 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V
BC17L 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
BC17R 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
BC18L 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
BC18R 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
BC19L 2202-000820 C-CERAMIC,MLC-AXIAL;5.6NF,20%,16V,Y5R,TP
BC19R 2202-000820 C-CERAMIC,MLC-AXIAL;5.6NF,20%,16V,Y5R,TP
BC20 2202-000806 C-CERAMIC,MLC-AXIAL;220PF,10%,50V,Y5P,TP
BC21 2401-001912 C-AL;1UF,20%,50V,GP,BK,5X11MM,2MM
BC22 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
BC23 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
BC24 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
BC3 2401-001895 C-AL;100UF,20%,16V,GP,BK,6.3X11MM,2
BC4L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC4R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC5L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC5R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC7 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
BC8 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
BC8L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC8R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BC9L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
Electrical Parts List
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 8-3
