BC9R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
BD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
BD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
BL3 2701-000179 INDUCTOR-AXIAL;33UH,10%,4.2X9.8MM
BQ1L 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300MW,4.7K,TO-92
BQ1R 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300MW,4.7K,TO-92
BQ2 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K-22K,TO-
BR1 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR2 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
BR3L 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR3R 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR4L 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR4R 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR5L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR5R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR6L 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR6R 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR7 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
BR7L 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR7R 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR8L 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2M
BR8R 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2M
BZD1 0403-000374 DIODE-ZENER;UZ9.1BSC,9.1V,8.89-9.29V,40
EC1 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
EC10 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
EC11 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
EC4 2201-000223 C-CERAMIC,DISC;12PF,5%,50V,CH,TP,5X3,5.0
EC5 2201-000506 C-CERAMIC,DISC;3PF,0.25PF,50V,NPO,4.0X3.
ED1 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
ED2 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
ED3 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
ED4 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
EQ1 0501-000394 TR-SMALL SIGNAL;KSC900-L,NPN,250MW,TO-92
EQ4 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
EQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
EQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
ER1 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER11 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
ER2 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
ER3 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
ER4 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
ER6 2001-000802 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
ER7 2001-000802 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
FC2 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V
FC3 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
FC4 2201-000426 C-CERAMIC,DISC;27pF,5%,50V,SL,TP,5x3,5
FC5 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC6 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V
FD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
FD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
FQ1 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250MW,TO-92
FQ2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250MW,TO-92
FR1 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR10 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR11 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR2 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR4 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR5 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR6 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP,1.8X3.2MM
FR7 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
FR8 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
FR9 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
HC1 2201-000247 C-CERAMIC,DISC;15pF,5%,50V,CH,TP,5x3,5
HC10 2201-000300 C-CERAMIC,DISC;1NF,20%,50V,Y5T,TP,5X3,5
HC11 2301-000410 C-FILM,PEF;220NF,10%,50V,-,-,-
HC2 2201-000423 C-CERAMIC,DISC;27PF,5%,50V,NPO,TP,5X3,2.
HC3 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
HC4 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
HC5 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
HC6 2401-000240 C-AL;100UF,20%,10V,GP,TP,6X11MM,5MM
HC7 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
HC8 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
HC9 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
HD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
HD4 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,
HR1 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR10 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR11 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR12 2001-001077 R-CARBON(S);150OHM,5%,1/2W,AA,TP,2.4X6.4
HR13 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
HR14 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR15 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR2 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR3 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR4 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR5 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR6 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR7 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
HR8 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HR9 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
HZD1 0403-000394 DIODE-ZENER;UZP5.6B,5.2-6.0V,1W,DO-41,TP
IC1 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
IC10 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
IC11 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
IC12 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
IC13 2401-001912 C-AL;1UF,20%,50V,GP,BK,5X11MM,2MM
IC14 2401-001912 C-AL;1UF,20%,50V,GP,BK,5X11MM,2MM
IC15 2202-000781 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,TP
IC15L 2301-000385 C-FILM,PEF;12NF,10%,50V,TP,6.5X8.5X3.2MM
IC15R 2301-000385 C-FILM,PEF;12NF,10%,50V,TP,6.5X8.5X3.2MM
IC16 2401-000778 C-AL;220UF,20%,10V,GP,-,6.3X11,2.5M
IC17 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,
IC18 2401-001912 C-AL;1UF,20%,50V,GP,BK,5X11MM,2MM
IC19 2401-001912 C-AL;1UF,20%,50V,GP,BK,5X11MM,2MM
IC2 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
IC20 2301-000430 C-FILM,PEF;33NF,10%,50V,TP,7.5X11X4MM,5M
IC21 2301-000430 C-FILM,PEF;33NF,10%,50V,TP,7.5X11X4MM,5M
IC22 2401-001912 C-AL;1UF,20%,50V,GP,BK,5X11MM,2MM
IC23 2202-000829 C-CERAMIC,MLC-AXIAL;820PF,10%,50V,Y5P,TP
IC24 2202-000806 C-CERAMIC,MLC-AXIAL;220PF,10%,50V,Y5P,TP
IC25 2301-000442 C-FILM,PEF;4.7NF,10%,50V,TP,5.5X7X3MM,5M
IC25 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
IC26 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
IC27 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0
IC28 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
IC29 2301-000442 C-FILM,PEF;4.7NF,10%,50V,TP,5.5X7X3MM,5M
IC3 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
IC4 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,
Electrical Parts List
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
8-4 Samsung Electronics
